| Type | Datasheet | Circuit | Marking | Channel | ID | VDSS | VGSS | VGS(th) | RDS(ON) | Qg | Ciss | Package | ||||
| (V) | (V) | (V) | 4.5V(mΩ) | 10V(mΩ) | ||||||||||||
| A | Min. | Min. | Min. | Max. | Typ | Max | Typ | Max | nC | pF | ||||||
| 重置全部 | / | / | / |
Reset
|
Reset
OK
|
Reset
OK
|
Reset
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | / | ||||||||||||||
| YFWG80N10AC |
|
|
YFW G80N10AC | N | 80 | 100 | ±20 | 1.2 | 2.5 | 7.5 | 9.4 | 5.5 | 6.4 | 43 | 2420 | TO-220C |
| YFWG80N10ASC |
|
|
YFW G80N10ASC | N | 80 | 100 | ±20 | 1.2 | 2.5 | 7.5 | 9.4 | 5.5 | 6.4 | 43 | 2420 | TO-263C |
| YFWG80N10TC |
|
|
YFW G80N10TC | N | 80 | 100 | ±20 | 1.2 | 2.5 | 7.5 | 9.4 | 5.5 | 6.4 | 43 | 2420 | TO-262C |
| YFWG220N10HAP |
|
|
YFW G220N10HAP | N | 220 | 100 | ±20 | 2 | 4 | 0 | 0 | 2.1 | 3 | 150 | 8600 | TO-247 |
| YFW4614S |
|
|
YFW 4614S | N+P | 8 | 40 | ±20 | 1 | 2.5 | 25 | 35 | 17 | 24 | 5.5 | 593 | SOP-8 |
| YFWG160N06AD |
|
|
YFW G160N06AD | N | 160 | 60 | ±20 | 2.2 | 3.4 | 0 | 0 | 2.3 | 3 | 42 | 4200 | TO-252 |
| YFWG160N06HAC |
|
|
YFW G160N06HAC | N | 160 | 60 | ±20 | 2 | 4 | 0 | 0 | 2.8 | 4 | 42 | 4200 | TO-220C |
| YFWG160N06HASC |
|
|
YFW G160N06HASC | N | 160 | 60 | ±20 | 2 | 4 | 0 | 0 | 2.8 | 4 | 42 | 4200 | TO-263C |
| YFWG80N06AD |
|
|
YFW G80N06AD | N | 80 | 60 | ±20 | 1.1 | 2.1 | 6.2 | 8 | 4.8 | 6.2 | 12 | 3850 | TO-252 |
| YFW10V03S |
|
|
YFW 10V03S | P+P | -10 | -30 | ±20 | -1 | -2.5 | 23 | 30 | 16 | 20 | 30 | 1550 | SOP-8 |
| YFW20N03DF |
|
|
YFW 20N03DF | N | 20 | 30 | ±20 | 1 | 2.5 | 15 | 20 | 10 | 13 | 15 | 584 | PDFN3*3-8L |
| YFW34N20AC |
|
|
YFW 34N20AC | N | 34 | 200 | ±30 | 2 | 4 | 0 | 0 | 65 | 90 | 60 | 2400 | TO-220C |
| YFW34N20ASC |
|
|
YFW 34N20ASC | N | 34 | 200 | ±30 | 2 | 4 | 0 | 0 | 65 | 90 | 60 | 2400 | TO-263C |
| YFW100N03AS |
|
|
YFW 100N03AS | N | 100 | 30 | ±20 | 1 | 2.5 | 5.4 | 7 | 3.4 | 4 | 51 | 2200 | TO-263 |
| YFW55N03DF |
|
|
YFW 55N03DF | N | 55 | 30 | ±20 | 1.1 | 2.5 | 10 | 13 | 6.5 | 7.5 | 24 | 1209 | PDFN3*3-8L |
| YFW90P06AS |
|
|
YFW 90P06AS | P | -90 | -60 | ±20 | -1 | -3 | 9 | 14 | 7 | 11 | 130 | 8500 | TO-263 |
| YFW50N04DF |
|
|
YFW 50N04DF | N | 50 | 40 | ±20 | 1 | 2.5 | 11 | 16 | 7.5 | 10 | 37 | 2400 | PDFN3*3-8L |
| 2N7002T |
|
|
K72 | N | 115 | 60 | ±20 | 1 | 2.5 | 1.1 | 7 | 0.9 | 5 | 20 | 50 | SOT-523 |
| YFWG25N10DF |
|
|
YFW G25N10DF | N | 25 | 100 | ±20 | 1.8 | 2.5 | 24.5 | 32 | 18.5 | 25 | 25 | 651 | PDFN3*3-8L |
| YFW160N04HAC |
|
|
YFW 160N04HAC | N | 160 | 40 | ±20 | 1.8 | 4 | 0 | 0 | 2 | 2.7 | 145 | 9500 | TO-220C |
| YFW160N04HASC |
|
|
YFW 160N04HASC | N | 160 | 40 | ±20 | 1.8 | 4 | 0 | 0 | 2 | 2.7 | 145 | 9500 | TO-263 |
| YFW80N03DF |
|
|
YFW 80N03DF | N | 80 | 30 | ±20 | 1 | 2.5 | 5.8 | 9 | 3.5 | 4.5 | 58 | 3089 | PDFN3*3-8L |
| YFW20N10DF |
|
|
YFW 20N10DF | N | 20 | 100 | ±20 | 1 | 2 | 35 | 45 | 33 | 40 | 20 | 1964 | PDFN3*3-8L |
| YFW20N02DF |
|
|
YFW 20N02DF | N | 20 | 20 | ±12 | 0.5 | 1 | 6.2 | 8 | 0 | 0 | 19 | 1458 | PDFN3*3-8L |
| YFW30N06DF |
|
|
YFW 30N06DF | N | 30 | 60 | ±20 | 1.2 | 2.5 | 28 | 40 | 21 | 30 | 12.6 | 1378 | PDFN3*3-8L |
| YFW50N06AC |
|
|
YFW 50N06AC | N | 50 | 60 | ±20 | 1 | 2 | 18.4 | 22.5 | 14.4 | 0 | 20 | 1714 | TO-220C |
| YFW23G04NF |
|
|
N+P | 23 | 40 | ±20 | 1 | 2.5 | 18 | 24 | 14 | 19 | 10 | 1013 | PDFN5*6-8L | |
| YFW100P03NF |
|
|
YFW 100P03NF | P | -100 | -30 | ±20 | -1.1 | -2.2 | 8.3 | 10 | 5 | 6.5 | 63 | 3500 | PDFN5*6-8L |
| YFW50N03DF |
|
|
YFW 50N03DF | N | 50 | 30 | ±20 | 1.2 | 2.2 | 15.8 | 20 | 9.4 | 12 | 4.2 | 870 | PDFN3*3-8L |
| YFW18P10NF |
|
|
YFW 18P10NF | P | -18 | -100 | ±20 | -1 | -2.5 | 85 | 120 | 80 | 100 | 65 | 3985 | PDFN5*6-8L |
| YFWG200N15APS |
|
|
YFW G200N15APS | N | 200 | 150 | ±20 | 2 | 4 | 0 | 0 | 6.2 | 7.5 | 18 | 5240 | TO-247S |
| YFW20P02BF |
|
|
YFW 20P02BF | P | -20 | -20 | ±12 | -0.4 | -1 | 11 | 15 | 0 | 0 | 15.8 | 1946 | DFN2*2-6L |
| YFW10N02BF |
|
|
YFW 10N02BF | N | 10 | 20 | ±12 | 0.45 | 1 | 11.5 | 15 | 0 | 0 | 3.9 | 1100 | DFN2*2-6L |
| YFWG200N08AC |
|
|
YFW G200N08AC | N | 200 | 80 | ±20 | 2 | 4 | 0 | 0 | 2.7 | 3.4 | 91 | 7000 | TO-252 |
| YFWG200N08ASC |
|
|
YFW G200N08ASC | N | 200 | 80 | ±20 | 2 | 4 | 0 | 0 | 2.7 | 3.4 | 91 | 7000 | TO-263C |
| YFWG50P10AC |
|
|
YFW G50P10AC | P | -50 | -100 | ±20 | -2 | -4 | 0 | 0 | 16 | 22 | 40 | 2100 | TO-220C |
| YFWG50P10ASC |
|
|
YFW G50P10ASC | P | -50 | -100 | ±20 | -2 | -4 | 0 | 0 | 16 | 22 | 40 | 2100 | TO-263C |
| YFW2302T |
|
|
2302 | N | 2.1 | 20 | ±8 | 0.65 | 1.2 | 0.045 | 0.06 | / | / | / | / | SOT-523 |
| YFWG200N04ASC |
|
|
YFW G200N04ASC | N | 200 | 40 | ±20 | 1 | 2.5 | 1.8 | 2.4 | 1.15 | 1.8 | 105 | 6150 | TO-263C |
| YFW120N04ASC |
|
|
YFW 120N04ASC | N | 120 | 40 | ±20 | 1 | 2.5 | 4.5 | 5.5 | 3.8 | 4.5 | 65 | 5125 | TO-263C |
| YFW120N04AC |
|
|
YFW 120N04AC | N | 120 | 40 | ± 20 | 1 | 2.5 | 4.5 | 5.5 | 3.8 | 4.5 | 65 | 5125 | TO-220C |
| YFW80N07ASC |
|
|
YFW 80N07ASC | N | 80 | 70 | ±20 | 2 | 4 | 0 | 0 | 7.05 | 9 | 75 | 3500 | TO-263C |
| YFW80N07AC |
|
|
YFW 80N07AC | N | 80 | 70 | ±20 | 2 | 4 | 0 | 0 | 7.05 | 9 | 75 | 3500 | TO-263C |
| YFW7P02MI |
|
|
7P02 | P | -7 | -20 | ±12 | -0.4 | -1 | 20 | 26 | / | / | 33.7 | 1200 | SOT23-3L |
| YFW5N06SI |
|
|
YFW5N06SI | N | 5 | 60 | ±20 | 1 | 2.5 | 27 | 38 | 23 | 31 | 2.2 | 1150 | SOT-89 |
| YFW3N06SI |
|
|
YFW3N06SI | N | 3 | 60 | ±20 | 1 | 2 | 90 | 120 | 80 | 100 | 14.6 | 510 | SOT-89 |
| YFW4N06SI |
|
|
YFW4N06SI | N | 4.8 | 60 | ±20 | 1.2 | 2.5 | 85 | 100 | 72 | 95 | 5 | 715 | SOT-89 |
| YFW6N03SI |
|
|
YFW6N03SI | N | 6 | 30 | ±12 | 0.5 | 1.5 | 29 | 35 | / | / | 6 | 800 | SOT-89 |
| YFW6N04SI |
|
|
YFW6N04SI | N | 6 | 40 | ±20 | 1 | 2.5 | 35 | 50 | 28 | 40 | 5 | 452 | SOT-89 |
| YFW8N06SI |
|
|
YFW8N06SI | N | 8.5 | 60 | ±20 | 1 | 2.5 | 33 | 45 | 28 | 40 | 20.3 | 1148 | SOT-89 |
| YFW2305 |
|
|
S5 | P | -4.1 | -20 | ±12 | -0.5 | -0.9 | 30 | 45 | 0 | 0 | 7.8 | 740 | SOT--23 |
| YFW13P10AD |
|
|
YFW 13P10AD | P | -10 | -100 | ±20 | -1 | -2.5 | 210 | 262 | 180 | 231 | 15.8 | 1110 | TO-252 |
| YFW2309 |
|
|
S9 | P | -2 | -60 | ±20 | -1.2 | -2.5 | 172 | 240 | 145 | 190 | 8.2 | 615 | SOT-23 |
| YFW100N03DF |
|
|
YFW 100N03DF | N | 100 | 30 | ±20 | 1.2 | 2.5 | 5 | 7 | 3 | 4 | 58 | 3089 | PDFN3*3-8L |
| YFW3134K |
|
|
34K | N | 0.75 | 20 | ±12 | 0.35 | 1.1 | 270 | 380 | 0 | 0 | 0 | 120 | SOT-23 |
| YFW15N03AS |
|
|
YFW 15N03AS | N | 15 | 30 | ±20 | 1.2 | 2.5 | 10.5 | 14 | 7.5 | 10 | 15 | 1350 | SOP-8 |
| YFW9435S |
|
|
YFW 9435S | P | -5.3 | -30 | ±20 | 0 | 0 | 65 | 85 | 45 | 55 | 12 | 1040 | SOP-8 |
| YFWG150N085NF |
|
|
YFW G150N085NF | N | 150 | 85 | ±20 | 2 | 4 | 0 | 0 | 3 | 4 | 62 | 4083 | PDFN5*6-8L |
| YFW4423S |
|
|
YFW 4423S | P | -17 | -30 | ±25 | -1.5 | -2.6 | 0 | 0 | 5.9 | 7.2 | 57 | 3033 | SOP-8 |
| YFW2307 |
|
|
2307 | P | -2.7 | -30 | ±20 | -1 | -3 | 0.11 | 0.138 | 0.073 | 0.088 | 6.2 | 340 | SOT-23 |
| YFW2304 |
|
|
2304 | N | 3.3 | 30 | ±20 | 1 | 2.2 | 57 | 75 | 37 | 60 | 4.5 | 6.7 | SOT-23 |
| BFS20 |
|
|
S2 | N | 0.2 | 0.025 | ±30 | 20 | 4 | 40 | 140 | - | 275 | SOT-23 | ||
| YFW50P02DF |
|
|
YFW 50P02DF | P | -50 | -20 | ±12 | -0.3 | -1 | 6.8 | 9 | / | / | 63 | 5783 | PDFN3*3-8L |
| YFW60P02NF | / | / | YFW 60P02NF | P | -60 | -20 | ±12 | -0.4 | -1.2 | / | / | / | / | 4.8 | 6.3 | PDFN5*6-8L |
| YFW40P04NF |
|
|
YFW 40P04NF | P | -40 | -40 | ±20 | -1 | -2.5 | 18 | 25 | 15 | 18 | 25 | 2760 | PDFN5*6-8L |
| YFW20P03DF |
|
|
YFW 20P03DF | P | -20 | -30 | ±20 | -1.2 | -2.5 | 30.5 | 40 | 18.8 | 25 | 19 | 900 | PDFN3*3-8L |
| YFW60P03NF | / | / | YFW 60P03NF | P | -60 | -30 | ±20 | -1 | -2 | / | / | 5 | 6.3 | 7.3 | 9.5 | PDFN5*6-8L |
| YFW50P02AD | / | / | YFW 50P02AD | P | -50 | -20 | ±12 | -0.65 | -1 | / | / | / | / | 6.6 | 8.6 | TO-252 |
| YFW60P02AD |
|
|
YFW 60P02AD | P | -60 | -20 | ±12 | -0.4 | -1 | 8 | 12 | / | / | 63 | 1600 | TO-252 |
| YFW40P04AD |
|
|
YFW 40P04AD | P | -40 | -40 | ±20 | -1 | -2.5 | 13 | 18 | 10 | 13 | 22.2 | 2757 | TO-252 |
| YFW20P03AD |
|
|
YFW 20P03AD | P | -20 | -30 | ±20 | -1.2 | -2.5 | 65 | 78 | 38 | 42 | 6.1 | 585 | TO-252 |
| YFW60P03AD |
|
|
YFW 60P03AD | P | -60 | -30 | ±20 | -1 | -2.5 | 10 | 15 | 7.2 | 9 | 37 | 3564 | TO-252 |
| YFW50P06AD |
|
|
YFW 50P06AD | P | -50 | -60 | ±20 | -1 | -2.5 | / | / | 25 | 30 | 75 | 4500 | TO-252 |
| YFW50P06ASC |
|
|
YFW 50P06ASC | P | -50 | -60 | ±20 | -1 | -2.5 | / | / | 25 | 30 | 73 | 4500 | TO-263C |
| YFW50P06AC |
|
|
YFW 50P06AC | P | -50 | -60 | ±20 | -1 | -2.5 | / | / | 25 | 30 | 73 | 4500 | TO-220C |
| YFW12N20DF | / | / | YFW 12N20DF | N | 12 | 20 | ±20 | / | 1.2 | / | / | / | / | 8 | 14 | PDFN3*3 |
| YFW55N20DF | / | / | YFW 55N20DF | N | 55 | 20 | ±20 | / | 1.2 | / | / | / | / | 5.2 | 6.5 | PDFN3*3 |
| YFW60N20DF | / | / | YFW 60N20DF | N | 60 | 20 | ±20 | / | 1.1 | / | / | / | / | 3.5 | 5.5 | PDFN3*3 |
| YFW75N20DF | / | / | YFW 75N20DF | N | 75 | 20 | ±20 | / | 1.1 | / | / | / | / | 2.5 | 3.5 | PDFN3*3 |
| YFW30N03DF |
|
|
YFW 30N03DF | N | 30 | 30 | ±20 | 1.1 | 2.2 | 9.5 | 13 | 6 | 8.5 | 22 | 1270 | PDFN3*3 |
| YFW40N30DF | / | / | YFW 40N30DF | N | 40 | 30 | ±20 | / | 2 | / | / | 6 | 7 | 8 | 10 | PDFN3*3 |
| YFW60N03DF |
|
|
YFW 60N03DF | N | 60 | 30 | ±20 | 1.0 | 2.5 | 7.4 | 9.6 | 4.7 | 6 | 34 | 1788 | PDFN3*3-8L |
| YFW65N30DF | / | / | YFW 65N30DF | N | 65 | 30 | ±20 | / | 2.2 | / | / | 3.8 | 4.3 | 5.5 | 7 | PDFN3*3 |
| YFW90N03DF |
|
|
YFW 90N03DF | N | 90 | 30 | ±20 | 1.1 | 2.1 | 5.3 | 7.2 | 3.6 | 4.5 | 48 | 1859 | PDFN3*3 |
| YFW110N30DF | / | / | YFW 110N30DF | N | 110 | 30 | ±20 | / | 1.6 | / | / | 2.5 | 4 | 4.5 | 7 | PDFN3*3 |
| YFW140N30DF | / | / | YFW 140N30DF | N | 140 | 30 | ±20 | / | 3 | / | / | 2 | 2.8 | 3.8 | 5 | PDFN3*3 |
| YFW170N30DF | / | / | YFW 170N30DF | N | 170 | 30 | ±20 | / | 2 | / | / | 1.35 | 1.65 | 1.8 | 2.2 | PDFN3*3 |
| YFW45N04DF | / | / | YFW 45N04DF | N | 45 | 40 | ±20 | / | 2.5 | / | / | 6 | 7.2 | 10 | 12 | PDFN3*3 |
| YFW9N40DF | / | / | YFW 9N40DF | N | 9 | 40 | ±20 | / | 2.5 | / | / | 22 | 29 | 28 | 40 | PDFN3*3 |
| YFW15N40DF | / | / | YFW 15N40DF | N | 15 | 40 | ±20 | / | 2.5 | / | / | 15 | 22 | 20 | 30 | PDFN3*3 |
| YFW40N40DF | / | / | YFW 40N40DF | N | 40 | 40 | ±20 | / | 2.5 | / | / | 10 | 13 | 15 | 19 | PDFN3*3 |
| YFW60N04DF |
|
|
YFW 60N04DF | N | 60 | 40 | ±20 | 1.0 | 2.5 | 9.0 | 12 | 5.5 | 7.5 | 18.8 | 2332 | PDFN3*3 |
| YFW90N04DF | / | / | YFW 90N04DF | N | 90 | 40 | ±20 | 0 | 2.5 | 0 | 0 | 4.2 | 6 | 6 | 8.5 | PDFN3*3 |
| YFW7N60DF | / | / | YFW 7N60DF | N | 7 | 60 | ±20 | / | 2.5 | / | / | 56 | 68 | 65 | 78 | PDFN3*3 |
| YFW9N40DF | / | / | YFW 9N40DF | N | 9 | 40 | ±20 | / | 2 | / | / | 24 | 29 | 28 | 34 | PDFN3*3 |
| YFW15N40DF | / | / | YFW 15N40DF | N | 15 | 40 | ±20 | / | 2.5 | / | / | 17 | 22 | 21 | 25 | PDFN3*3 |
| YFW20N60DF | / | / | YFW 20N60DF | N | 20 | 60 | ±20 | / | 2.5 | / | / | 22.5 | 29 | 28 | 38 | PDFN3*3 |
| YFW30N60DF | / | / | YFW 30N60DF | N | 30 | 60 | ±20 | / | 3 | / | / | 23 | 30 | 30 | 40 | PDFN3*3 |
| YFWG35N60DF | / | / | YFW G35N60DF | N | 35 | 60 | ±20 | / | 3 | / | / | 9 | 11 | 14 | 19 | PDFN3*3 |
| YFW50N60DF | / | / | YFW 50N60DF | N | 50 | 60 | ±20 | / | 3 | / | / | 15 | 18 | 18 | 22 | PDFN3*3 |
| YFWG50N60DF | / | / | YFW G50N60DF | N | 50 | 60 | ±20 | / | 3 | / | / | 5 | 6 | 8 | 11 | PDFN3*3 |
| YFW7N100DF | / | / | YFW 7N100DF | N | 7 | 100 | ±20 | / | 3 | / | / | 68 | 92 | 100 | 150 | PDFN3*3 |
| YFW20N100DF | / | / | YFW 20N100DF | N | 20 | 100 | ±20 | / | 3 | / | / | 20 | 25 | 27 | 38 | PDFN3*3 |
| YFW38N100DF | / | / | YFW 38N100DF | N | 38 | 100 | ±20 | / | 2 | / | / | 11.6 | 14 | 16.5 | 22 | PDFN3*3 |
| YFW40N016NF | / | / | YFW 40N016NF | N | 40 | 16 | ±12 | 0.4 | 1.1 | 6.5 | 8.5 | / | / | / | / | PDFN5*6-8L |
| YFW50N016NF | / | / | YFW 50N016NF | N | 50 | 16 | ±12 | 0.5 | 1.1 | 5 | 6.5 | / | / | / | / | PDFN5*6-8L |
| YFW25N02NF | / | / | YFW 25N02NF | N | 25 | 20 | ±12 | 0.5 | 1.1 | 9.3 | 12 | / | / | / | / | PDFN5*6-8L |
| YFW30N02NF | / | / | YFW 30N02NF | N | 30 | 20 | ±10 | 0.45 | 1.5 | 7.6 | 11.6 | / | / | / | / | PDFN5*6-8L |
| YFW50N02NF |
|
|
YFW 50N02NF | N | 50 | 20 | ±12 | 0.4 | 1.1 | 6.2 | 8.5 | / | / | 19 | 1458 | PDFN5*6-8L |
| YFW60N02NF |
|
|
YFW 60N02NF | N | 60 | 20 | ±12 | 0.5 | 1.2 | 4.8 | 6.5 | / | / | 23 | 1832 | PDFN5*6-8L |
| YFW75N02NF | / | / | YFW 75N02NF | N | 75 | 20 | ±10 | 0.4 | 1.1 | / | / | / | / | / | / | PDFN5*6-8L |
| YFW90N02NF |
|
|
YFW 90N02NF | N | 90 | 20 | ±12 | 0.5 | 1 | 1.9 | 2.5 | 1.6 | 2 | 77 | 4307 | PDFN5*6-8L |
| YFW180N02NF | / | / | YFW 180N02NF | N | 180 | 20 | ±12 | 0.6 | 1.3 | / | / | 2.1 | 2.7 | / | / | PDFN5*6-8L |
| YFW20N03NF | / | / | YFW 20N03NF | N | 20 | 30 | ±20 | 1 | 2.5 | / | / | 18 | 25 | / | / | PDFN5*6-8L |
| YFW30N03NF | / | / | YFW 30N03NF | N | 30 | 30 | ±20 | 1 | 2.2 | / | / | 9.4 | 12.2 | / | / | PDFN5*6-8L |
| YFW40N03NF | / | / | YFW 40N03NF | N | 40 | 30 | ±20 | 1 | 2.5 | / | / | 10 | 12 | 12 | 15 | PDFN5*6-8L |
| YFW60N03NF |
|
|
YFW 60N03NF | N | 60 | 30 | ±20 | 1 | 2.5 | 8 | 13 | 6 | 8.5 | 12.8 | 1317 | PDFN5*6-8L |
| YFW70N03NF |
|
|
YFW 70N03NF | N | 70 | 30 | ±20 | 1 | 2.5 | 6.5 | 8.5 | 3.5 | 4.5 | 20 | 2295 | PDFN5*6-8L |
| YFW80N03NF |
|
|
YFW 80N03NF | N | 80 | 30 | ±20 | 1 | 2.5 | 5.3 | 6.5 | 2.9 | 4 | 42 | 2200 | PDFN5*6-8L |
| YFW100N03NF |
|
|
YFW 100N03NF | N | 100 | 30 | ±20 | 1 | 2.5 | 5 | 8 | 3 | 3.8 | 51 | 2200 | PDFN5*6-8L |
| YFW120N03NF |
|
|
YFW 120N03NF | N | 120 | 30 | ±20 | 1.2 | 2.5 | 2.5 | 4.5 | 1.5 | 2.4 | 56.9 | 4345 | PDFN5*6-8L |
| YFW150N03NF |
|
|
YFW 150N03NF | N | 150 | 30 | ±20 | 1.2 | 2.5 | 2.3 | 3.2 | 1.4 | 2 | 70 | 4930 | PDFN5*6-8L |
| YFW190N03NF |
|
|
YFW 190N03NF | N | 190 | 30 | ±20 | 1 | 2.5 | 2.45 | 3.1 | 1.85 | 2.3 | 93 | 6515 | PDFN5*6-8L |
| YFW30N04NF | / | / | YFW 30N04NF | N | 30 | 40 | ±20 | 1 | 2.5 | / | / | 14 | 18 | / | / | PDFN5*6-8L |
| YFW40N04NF | / | / | YFW 40N04NF | N | 40 | 40 | ±20 | 1 | 2.5 | / | / | 13 | 17 | / | / | PDFN5*6-8L |
| YFW60N04NF |
|
|
YFW 60N04NF | N | 60 | 40 | ±20 | 1 | 2.5 | 13.5 | 16.5 | 10.5 | 13.5 | 10.7 | 1314 | PDFN5*6-8L |
| YFW80N04NF |
|
|
YFW 80N04NF | N | 80 | 40 | ±20 | 1.1 | 2.4 | 8 | 12 | 5.5 | 7 | 54.3 | 2662 | PDFN5*6-8L |
| YFW100N04NF |
|
|
YFW 100N04NF | N | 100 | 40 | ±20 | 1.2 | 2.2 | 3.8 | 5.3 | 2.5 | 3.2 | 22.7 | 2648 | PDFN5*6-8L |
| YFW120N04NF |
|
|
YFW 120N04NF | N | 120 | 40 | ±20 | 1 | 2.5 | 5.5 | 8 | 3.5 | 5 | 24 | 1820 | PDFN5*6-8L |
| YFW130N04NF | / | / | YFW 130N04NF | N | 130 | 40 | ±20 | 2 | 4 | / | / | 2.8 | 3.5 | / | / | PDFN5*6-8L |
| YFW140N04NF |
|
|
YFW 140N04NF | N | 140 | 40 | ±20 | 1 | 2.2 | 2.5 | 3.5 | 1.85 | 2.7 | 170 | 7800 | PDFN5*6-8L |
| YFWG180N04NF | / | / | YFW G180N04NF | N | 180 | 40 | ±20 | 1 | 2.5 | / | / | 1.6 | 2.1 | / | / | PDFN5*6-8L |
| YFWG195N04NF | / | / | YFW G195N04NF | N | 195 | 40 | ±20 | 1 | 2.5 | / | / | 1.1 | 1.3 | / | / | PDFN5*6-8L |
| YFWG200N04NF | / | / | YFW G200N04NF | N | 200 | 40 | ±20 | 1 | 2.5 | / | / | 0.5 | 0.74 | / | / | PDFN5*6-8L |
| YFW15N06NF |
|
|
YFW 15N06NF | N | 15 | 60 | ±20 | 1 | 2.5 | / | / | 38 | 49 | / | / | PDFN5*6-8L |
| YFW20N06NF | / | / | YFW 20N06NF | N | 20 | 60 | ±20 | 1 | 2.5 | / | / | 26 | 33 | / | / | PDFN5*6-8L |
| YFW30N06NF |
|
|
YFW 30N06NF | N | 30 | 60 | ±20 | 1.6 | 2.5 | / | / | 22.5 | 29 | / | / | PDFN5*6-8L |
| YFW40N06NF | / | / | YFW 40N06NF | N | 40 | 60 | ±20 | 1.2 | 2 | / | / | 20 | 24 | / | / | PDFN5*6-8L |
| YFW50N06NF |
|
|
YFW 50N06NF | N | 50 | 60 | ±20 | 1.2 | 2.5 | / | / | 13.5 | 17 | / | / | PDFN5*6-8L |
| YFW60N06NF |
|
|
YFW 60N06NF | N | 60 | 60 | ±20 | 1 | 2.5 | 16 | 25 | 12 | 17 | 45 | 2030 | PDFN5*6-8L |
| YFW80N07NF | / | / | YFW 80N07NF | N | 80 | 70 | ±20 | 2 | 4 | / | / | 6.8 | 9 | / | / | PDFN5*6-8L |
| YFW80N06NF |
|
|
YFW 80N06NF | N | 80 | 60 | ±20 | 1 | 2.5 | 6.4 | 10 | 4.7 | 6 | 30 | 2136 | PDFN5*6-8L |
| YFWG160N06NF |
|
|
YFW G160N06NF | N | 160 | 60 | ±20 | 2 | 4 | / | / | 2.8 | 3 | 42 | 4200 | PDFN5*6-8L |
| YFW100N08NF | / | / | YFW 100N08NF | N | 100 | 80 | ±20 | 2 | 4 | / | / | 5.4 | 6.5 | / | / | PDFN5*6-8L |
| YFWG120N085NF |
|
|
YFW G120N085NF | N | 120 | 85 | ±20 | 2 | 4 | / | / | 4.5 | 5 | 56 | 4010 | PDFN5*6-8L |
| YFW15N10NF | / | / | YFW 15N10NF | N | 15 | 100 | ±20 | 1 | 2.5 | / | / | 88 | 110 | / | / | PDFN5*6-8L |
| YFWG19N10NF | / | / | YFW G19N10NF | N | 19 | 100 | ±20 | 2 | 3.8 | / | / | 73 | 90 | / | / | PDFN5*6-8L |
| YFW20N10NF | / | / | YFW 20N10NF | N | 20 | 100 | ±20 | 1.2 | 2.5 | / | / | 65 | 85 | / | / | PDFN5*6-8L |
| YFW30N10NF | / | / | YFW 30N10NF | N | 30 | 100 | ±20 | 1 | 2.2 | / | / | 37 | 48 | / | / | PDFN5*6-8L |
| YFW40N10NF | / | / | YFW 40N10NF | N | 40 | 100 | ±20 | 2 | 4 | / | / | 24 | 31 | / | / | PDFN5*6-8L |
| YFWG50N10NF |
|
|
YFW G50N10NF | N | 50 | 100 | ±20 | 1.2 | 2.5 | / | / | 15 | 18.5 | / | / | PDFN5*6-8L |
| YFWG60N10NF |
|
|
YFW G60N10NF | N | 60 | 100 | ±20 | 1.2 | 2.5 | 12 | 14 | 9 | 12 | 28.9 | 1998.1 | PDFN5*6-8L |
| YFWG80N10NF |
|
|
YFW G80N10NF | N | 80 | 100 | ±20 | 1.2 | 2.5 | 7.5 | 9.4 | 5.5 | 6.4 | 43 | 2420 | PDFN5*6-8L |
| YFWG110N10NF |
|
|
YFW G110N10NF | N | 110 | 100 | ±20 | 1.2 | 2.5 | 6.6 | 9 | 4.2 | 6.0 | 75 | 4400 | PDFN5*6-8L |
| YFWG120N10NF |
|
|
YFW G120N10NF | N | 120 | 100 | ±20 | 2 | 4 | / | / | 4.5 | 5.6 | 110 | 4350 | PDFN5*6-8L |
| YFW40N016AD | / | / | YFW 40N016AD | N | 40 | 16 | ±12 | 0.4 | 1.1 | / | / | / | / | / | / | TO-252 |
| YFW50N016AD | / | / | YFW 50N016AD | N | 50 | 16 | ±12 | 0.5 | 1.1 | / | / | / | / | / | / | TO-252 |
| YFW25N02AD | / | / | YFW 25N02AD | N | 25 | 20 | ±12 | 0.5 | 1.1 | / | / | / | / | / | / | TO-252 |
| YFW30N20AD | / | / | YFW 30N20AD | N | 30 | 20 | ±10 | 0.45 | 1.5 | / | / | / | / | / | / | TO-252 |
| YFW50N02AD | / | / | YFW 50N02AD | N | 50 | 20 | ±12 | 0.5 | 1 | / | / | / | / | / | / | TO-252 |
| YFW60N02AD |
|
|
YFW 60N02AD | N | 60 | 20 | ±12 | 0.5 | 1.7 | 4.1 | 5.5 | / | / | 32 | 2500 | TO-252 |
| YFW75N02AD | / | / | YFW 75N02AD | N | 75 | 20 | ±10 | 0.4 | 1.1 | / | / | / | / | / | / | TO-252 |
| YFW90N02AD |
|
|
YFW 90N02AD | N | 90 | 20 | ±12 | 0.5 | 1 | 2.8 | 3.5 | / | / | 48 | 3200 | TO-252 |
| YFW180N02AD | / | / | YFW 180N02AD | N | 180 | 20 | ±12 | 0.6 | 1.3 | / | / | 2.1 | 2.7 | / | / | TO-252 |
| YFW20N03AD |
|
|
YFW 20N03AD | N | 20 | 30 | ±20 | 1.2 | 2.5 | 28.5 | 38 | 15.6 | 25 | 4.9 | 216 | TO-252 |
| YFW30N03AD |
|
|
YFW 30N03AD | N | 30 | 30 | ±20 | 0.5 | 2 | 12 | 15 | 10 | 12 | 17.5 | 938 | TO-252 |
| YFW40N03AD | / | / | YFW 40N03AD | N | 40 | 30 | ±20 | 1 | 2.5 | / | / | 7.6 | 10 | / | / | TO-252 |
| YFW60N03AD |
|
|
YFW 60N03AD | N | 60 | 30 | ±20 | 1 | 2.5 | 8.5 | 13 | 6 | 8.5 | 12.8 | 1317 | TO-252 |
| YFW70N03AD | / | / | YFW 70N03AD | N | 70 | 30 | ±20 | 1 | 2.4 | / | / | 4 | 7 | / | / | TO-252 |
| YFW80N03AD |
|
|
YFW 80N03AD | N | 80 | 30 | ±20 | 1 | 2.4 | / | / | 3.8 | 5 | / | / | TO-252 |
| YFW100N03AD |
|
|
YFW 100N03AD | N | 100 | 30 | ±20 | 1 | 2.5 | / | / | 3.4 | 5.1 | 51 | 2200 | TO-252 |
| YFW120N03AD | / | / | YFW 120N03AD | N | 120 | 30 | ±20 | 1.2 | 2.2 | / | / | 2.8 | 3.6 | / | / | TO-252 |
| YFW150N03AD |
|
|
YFW 150N03AD | N | 150 | 30 | ±20 | 1.2 | 2.2 | / | / | 2.6 | 3.4 | / | / | TO-252 |
| YFW180N03AD |
|
|
YFW 180N03AD | N | 180 | 30 | ±20 | 1.2 | 2.5 | 3 | 3.8 | 2.1 | 3.2 | 56.9 | 5850 | TO-252 |
| YFW190N03AD | / | / | YFW 190N03AD | N | 190 | 30 | ±20 | 1 | 2.5 | / | / | 1.85 | 2.3 | / | / | TO-252 |
| YFW30N04AD |
|
|
YFW 30N04AD | N | 30 | 40 | ±20 | 1 | 2.5 | 18 | 30 | 14 | 23 | 23 | 1050 | TO-252 |
| YFW40N04AD | / | / | YFW 40N04AD | N | 40 | 40 | ±20 | 1 | 2.5 | / | / | 13 | 17 | / | / | TO-252 |
| YFW60N04AD |
|
|
YFW 60N04AD | N | 60 | 40 | ±20 | 1 | 2.5 | 16.8 | 24.9 | 14.9 | 19.8 | 10.7 | 1314 | TO-252 |
| YFW80N04AD |
|
|
YFW 80N04AD | N | 80 | 40 | ±20 | 1.1 | 2.4 | 8 | 12 | 5.5 | 7 | 54.3 | 2662 | TO-252 |
| YFW100N04SD | / | / | YFW 100N04SD | N | 100 | 40 | ±20 | 1.3 | 2.3 | / | / | 4.5 | 5.9 | / | / | TO-252 |
| YFW100N04AD |
|
|
YFW 100N04AD | N | 100 | 40 | ±20 | 1 | 2.5 | 5.8 | 9 | 4.5 | 6.5 | 28 | 3354 | TO-252 |
| YFW120N04AD |
|
|
YFW 120N04AD | N | 120 | 40 | ±20 | 1.2 | 2.2 | 3.8 | 5.3 | 2.5 | 3.2 | 22.7 | 2648 | TO-252 |
| YFW130N04AD | / | / | YFW 130N04AD | N | 130 | 40 | ±20 | 2 | 4 | / | / | 2.8 | 3.5 | / | / | TO-252 |
| YFW140N04AD |
|
|
YFW 140N04AD | N | 140 | 40 | ±20 | 1 | 2.2 | 2.5 | 3.5 | 1.85 | 2.7 | 170 | 7800 | TO-252 |
| YFWG180N04AD | / | / | YFW G180N04AD | N | 180 | 40 | ±20 | 1 | 2.5 | / | / | 1.6 | 2.1 | / | / | TO-252 |
| YFWG195N04AD | / | / | YFW G195N04AD | N | 195 | 40 | ±20 | 1 | 2.5 | / | / | 1.1 | 1.3 | / | / | TO-252 |
| YFWG200N04AD | / | / | YFW G200N04AD | N | 200 | 40 | ±20 | 1 | 2.5 | / | / | 0.5 | 0.74 | / | / | TO-252 |
| YFW15N06AD |
|
|
YFW 15N06AD | N | 15 | 60 | ±20 | 1 | 2.5 | 35 | 48 | 28 | 37 | 19 | 1050 | TO-252 |
| YFW20N06AD |
|
|
YFW 20N06AD | N | 20 | 60 | ±20 | 1.2 | 2.5 | 25 | 38 | 20 | 30 | 25 | 1100 | TO-252 |
| YFW30N06AD |
|
|
YFW 30N06AD | N | 30 | 60 | ±20 | 1 | 2.5 | 26 | 40 | 18 | 28 | 30 | 1750 | TO-252 |
| YFW40N06AD | / | / | YFW 40N06AD | N | 40 | 60 | ±20 | 1.2 | 2 | / | / | 20 | 24 | / | / | TO-252 |
| YFW50N06AD |
|
|
YFW 50N06AD | N | 50 | 60 | ±20 | 1 | 2 | 18 | 22 | 14 | 17 | 20 | 1714 | TO-252 |
| YFW60N06AD |
|
|
YFW 60N06AD | N | 60 | 60 | ±20 | 1 | 2.5 | 16 | 25 | 12 | 17 | 45 | 2030 | TO-252 |
| YFW80N07AD |
|
|
YFW 80N07AD | N | 80 | 70 | ±20 | 2 | 4 | / | / | 6.5 | 8.6 | 35 | 4062 | TO-252 |
| YFW80N06AD |
|
|
YFW 80N06AD | N | 80 | 60 | ±20 | 2 | 4 | / | / | 9 | 12 | 12 | 3750 | TO-252 |
| YFWG160N06HAD |
|
|
YFW G160N06HAD | N | 160 | 60 | ±20 | 2 | 4 | / | / | 2.8 | 3 | 42 | 4200 | TO-252 |
| YFWG100N08AD | / | / | YFW G100N08AD | N | 100 | 80 | ±20 | 2 | 4 | / | / | 5.4 | 6.5 | / | / | TO-252 |
| YFWG120N085AD |
|
|
YFW G120N085AD | N | 120 | 85 | ±20 | 2 | 4 | / | / | 4.5 | 5 | 56 | 3365 | TO-252 |
| YFWG150N085AD | / | / | YFW G150N085AD | N | 150 | 85 | ±20 | 2 | 4 | / | / | 3.2 | 4 | / | / | TO-252 |
| YFW15N10AD |
|
|
YFW 15N10AD | N | 15 | 100 | ±20 | 1 | 2.5 | 96 | 140 | 88 | 110 | 13 | 891 | TO-252 |
| YFWG19N10AD | / | / | YFW G19N10AD | N | 19 | 100 | ±20 | 2 | 3.8 | / | / | 73 | 90 | / | / | TO-252 |
| YFW20N10AD |
|
|
YFW 20N10AD | N | 20 | 100 | ±20 | 1.2 | 2.5 | 75 | 100 | 65 | 85 | 11.9 | 1110 | TO-252 |
| YFW30N10AD |
|
|
YFW 30N10AD | N | 30 | 100 | ±20 | 1 | 2.2 | 39 | 55 | 36 | 48 | 20 | 1964 | TO-252 |
| YFW40N10AD |
|
|
YFW 40N10AD | N | 40 | 100 | ±20 | 2 | 4 | 36 | / | 24 | 31 | 38 | 2180 | TO-252 |
| YFWG50N10AD |
|
|
YFW G50N10AD | N | 50 | 100 | ±20 | 1.2 | 2.5 | / | / | 15 | 18.5 | / | / | TO-252 |
| YFWG60N10AD |
|
|
YFW G60N10AD | N | 60 | 100 | ±20 | 1 | 2.5 | 10 | 12 | 8 | 10 | 49.9 | 2604 | TO-252 |
| YFWG80N10AD |
|
|
YFW G80N10AD | N | 80 | 100 | ±20 | 1.2 | 2.5 | 7.5 | 9.4 | 5.5 | 6.4 | 43 | 2420 | TO-252 |
| YFWG100N10AD |
|
|
YFW G100N10AD | N | 100 | 100 | ±20 | 1.2 | 2.3 | 8.7 | 10.5 | 6 | 8 | 45 | 3320 | TO-252 |
| YFWG120N10AD |
|
|
YFW G120N10AD | N | 120 | 100 | ±20 | 2 | 4 | / | / | 4.5 | 5.62 | / | / | TO-252 |
| YFWG130N10AD | / | / | YFW G130N10AD | N | 130 | 100 | ±20 | 2 | 4 | / | / | 3.4 | 4.25 | / | / | TO-252 |
| YFW150N03ASC |
|
|
YFW 150N03ASC | N | 150 | 30 | ±20 | 1.2 | 2.2 | / | / | 2.6 | 3.4 | / | / | TO-263C |
| YFW180N03ASC | / | / | YFW 180N03ASC | N | 180 | 30 | ±20 | 1 | 2.5 | / | / | 2.1 | 2.7 | / | / | TO-263C |
| YFW190N03ASC | / | / | YFW 190N03ASC | N | 190 | 30 | ±20 | 1 | 2.5 | / | / | 1.85 | 2.3 | / | / | TO-263C |
| YFW40N04ASC | / | / | YFW 40N04ASC | N | 40 | 40 | ±20 | 1 | 2.5 | / | / | 13 | 17 | / | / | TO-263C |
| YFW140N04ASC |
|
|
YFW 140N04ASC | N | 140 | 40 | ±20 | 1 | 2.5 | / | / | 1.9 | 2.8 | / | / | TO-263C |
| YFWG180N04ASC | / | / | YFW G180N04ASC | N | 180 | 40 | ±20 | 1 | 2.5 | / | / | 1.6 | 2.1 | / | / | TO-263C |
| YFW120N06ASC |
|
|
YFW 120N06ASC | N | 120 | 60 | ±20 | 2.0 | 4 | / | / | 3.5 | 4.4 | 105 | 5040 | TO-263C |
| YFWG160N06ASC |
|
|
YFW G160N06ASC | N | 160 | 60 | ±20 | 1.1 | 2.1 | 2.6 | 3.4 | 2.2 | 2.6 | 86 | 5460 | TO-263C |
| YFWG180N06ASC | / | / | YFW G180N06ASC | N | 180 | 60 | ±20 | 2 | 4 | / | / | 2 | 2.3 | / | / | TO-263C |
| YFWG100N08ASC | / | / | YFW G100N08ASC | N | 100 | 80 | ±20 | 2 | 4 | / | / | 5.4 | 6.5 | / | / | TO-263C |
| YFWG120N085ASC |
|
|
YFW G120N085ASC | N | 120 | 85 | ±20 | 2 | 4 | / | / | 4.1 | 5 | 56 | 3365 | TO-263C |
| YFWG150N085ASC |
|
|
YFW G150N085ASC | N | 150 | 85 | ±20 | 2 | 4 | / | / | 3.2 | 4 | 62 | 4083 | TO-263C |
| YFWG160N08ASC | / | / | YFW G160N08ASC | N | 160 | 80 | ±20 | 2 | 4 | / | / | 3.3 | 3.9 | / | / | TO-263C |
| YFWG180N08ASC | / | / | YFW G180N08ASC | N | 180 | 80 | ±20 | 2 | 4 | / | / | 3 | 3.6 | / | / | TO-263C |
| YFWG220N08ASC | / | / | YFW G220N08ASC | N | 220 | 80 | ±20 | 2 | 4 | / | / | 2.3 | 3.2 | / | / | TO-263C |
| YFWG250N08ASC | / | / | YFW G250N08ASC | N | 220 | 80 | ±20 | 2 | 4 | / | / | 2.1 | 2.6 | / | / | TO-263C |
| YFWG330N08ASC | / | / | YFW G330N08ASC | N | 330 | 80 | ±20 | 2 | 4 | / | / | 1.1 | 1.4 | / | / | TO-263C |
| YFW135N09ASC | / | / | YFW 135N09ASC | N | 135 | 90 | ±20 | 2 | 4 | / | / | 4 | 5.3 | / | / | TO-263C |
| YFW40N10ASC | / | / | YFW 40N10ASC | N | 40 | 100 | ±20 | 2 | 4 | / | / | 24 | 31 | / | / | TO-263C |
| YFWG50N10ASC |
|
|
YFW G50N10ASC | N | 50 | 100 | ±20 | 1.2 | 2.5 | 18.5 | 24 | 15.25 | 18.5 | 28.5 | 1980 | TO-263C |
| YFWG60N10ASC | / | / | YFW G60N10ASC | N | 60 | 100 | ±20 | 1.2 | 2.5 | / | / | 6.4 | 7.7 | / | / | TO-263C |
| YFWG80N10ASC | / | / | YFW G80N10ASC | N | 80 | 100 | ±20 | 1.2 | 2.5 | / | / | 6 | 7.9 | / | / | TO-263C |
| YFWG100N10ASC | / | / | YFW G100N10ASC | N | 100 | 100 | ±20 | 1.2 | 2.5 | / | / | 5.6 | 6.4 | / | / | TO-263C |
| YFWG120N10ASC |
|
|
YFW G120N10ASC | N | 120 | 100 | ±20 | 2 | 4 | / | / | 4.5 | 5.6 | 110 | 4350 | TO-263C |
| YFWG130N10ASC |
|
|
YFW G130N10ASC | N | 130 | 100 | ±20 | 2 | 4 | / | / | 3.4 | 4.25 | 110 | 6000 | TO-263C |
| YFWG220N10ASC | / | / | YFW G220N10ASC | N | 220 | 100 | ±20 | 2 | 4 | / | / | 3.1 | 3.7 | / | / | TO-263C |
| YFWG230N10ASC | / | / | YFW G230N10ASC | N | 230 | 100 | ±20 | 2 | 4 | / | / | 3 | 3.75 | / | / | TO-263C |
| YFWG240N10ASC |
|
|
YFW G240N10ASC | N | 240 | 100 | ±20 | 2 | 4 | / | / | 2.3 | 2.9 | 143 | 9500 | TO-263C |
| YFWG280N10ASC | / | / | YFW G280N10ASC | N | 280 | 100 | ±20 | 2 | 4 | / | / | 1.9 | 2.2 | / | / | TO-263C |
| YFWG320N10ASC | / | / | YFW G320N10ASC | N | 320 | 100 | ±20 | 2 | 4 | / | / | 1.6 | 2.2 | / | / | TO-263C |
| YFWG40N12ASC | / | / | YFW G40N12ASC | N | 40 | 120 | ±20 | 2 | 4 | / | / | 10 | 13 | / | / | TO-263C |
| YFWG160N12ASC | / | / | YFW G160N12ASC | N | 160 | 120 | ±20 | 2 | 4 | / | / | 3.8 | 4.2 | / | / | TO-263C |
| YFWG210N12ASC | / | / | YFW G210N12ASC | N | 210 | 120 | ±20 | 2 | 4 | / | / | 2.9 | 3.6 | / | / | TO-263C |
| YFWG90N15ASC |
|
|
YFW G90N15ASC | N | 90 | 150 | ±20 | 2.5 | 4.5 | / | / | 8.2 | 10 | 30 | 2181 | TO-263C |
| YFWG130N15ASC |
|
|
YFW G130N15ASC | N | 130 | 150 | ±20 | 2.5 | 4.5 | / | / | 5.2 | 6.5 | 83 | 5800 | TO-263C |
| YFWG200N15ASC | / | / | YFW G200N15ASC | N | 200 | 150 | ±20 | 2 | 4 | / | / | 4 | 5 | / | / | TO-263C |
| YFWG220N15ASC |
|
|
YFW G220N15ASC | N | 220 | 150 | ±20 | 2.5 | 4.5 | / | / | 4 | 4.8 | 87 | 6535 | TO-263C |
| YFW18N20ASC | / | / | YFW 18N20ASC | N | 18 | 200 | ±30 | 2 | 4 | / | / | 100 | 120 | / | / | TO-263C |
| YFW28N20ASC | / | / | YFW 28N20ASC | N | 28 | 200 | ±30 | 2 | 4 | / | / | 70 | 90 | / | / | TO-263C |
| YFW34N20ASC | / | / | YFW 34N20ASC | N | 34 | 200 | ±30 | 2 | 4 | / | / | 60 | 70 | / | / | TO-263C |
| YFW50N20ASC |
|
|
YFW 50N20ASC | N | 50 | 200 | ±30 | 2 | 4 | / | / | 48 | 58 | 105 | 2900 | TO-263C |
| YFWG100N20ASC | / | / | YFW G100N20ASC | N | 100 | 200 | ±20 | 2 | 4 | / | / | 18 | 20.5 | / | / | TO-263C |
| YFWG130N20ASC |
|
|
YFW G130N20ASC | N | 130 | 200 | ±20 | 2.5 | 4.5 | / | / | 9.4 | 10 | 48 | 3318 | TO-263C |
| YFWG150N20ASC | / | / | YFW G150N20ASC | N | 150 | 200 | ±20 | 2.5 | 4.5 | / | / | 6.6 | 10 | / | / | TO-263C |
| YFWG300N03TL | / | / | YFW G300N03TL | N | 300 | 30 | ±20 | 1 | 1.7 | / | / | 0.8 | 1 | / | / | TOLL-8L |
| YFWG220N04TL |
|
|
YFW G220N04TL | N | 220 | 40 | ±20 | 1.0 | 2.5 | 2.7 | 4.0 | 1.9 | 2.5 | 95 | 3162 | TOLL-8L |
| YFWG240N04TL | / | / | YFW G240N04TL | N | 240 | 40 | ±20 | 1 | 1.8 | / | / | 1 | 1.4 | / | / | TOLL-8L |
| YFWG260N06TL | / | / | YFW G260N06TL | N | 260 | 60 | ±20 | 1.25 | 3 | / | / | 1.6 | 2 | / | / | TOLL-8L |
| YFWG280N06TL | / | / | YFW G280N06TL | N | 280 | 60 | ±20 | 1.25 | 3 | / | / | 1.25 | 1.5 | / | / | TOLL-8L |
| YFWG290N06TL | / | / | YFW G290N06TL | N | 290 | 60 | ±20 | 1.25 | 3 | / | / | 1.2 | 1.4 | / | / | TOLL-8L |
| YFWG480N08TL | / | / | YFW G480N08TL | N | 480 | 80 | ±20 | 2 | 4 | / | / | 1 | 1.2 | / | / | TOLL-8L |
| YFWG160N085TL | / | / | YFW G160N085TL | N | 160 | 85 | ±20 | 2 | 4 | / | / | 3.7 | 4 | / | / | TOLL-8L |
| YFWG200N085TL | / | / | YFW G200N085TL | N | 200 | 85 | ±20 | 2 | 4 | / | / | 2.6 | 3.2 | / | / | TOLL-8L |
| YFWG240N085TL | / | / | YFW G240N085TL | N | 240 | 85 | ±20 | 2 | 4 | / | / | 2 | 2.7 | / | / | TOLL-8L |
| YFWG260N085TL | / | / | YFW G260N085TL | N | 260 | 85 | ±20 | 2 | 4 | / | / | 1.9 | 2.4 | / | / | TOLL-8L |
| YFWG320N085TL | / | / | YFW G320N085TL | N | 320 | 85 | ±20 | 2 | 4 | / | / | 1.3 | 1.8 | / | / | TOLL-8L |
| YFWG160N10TL | / | / | YFW G160N10TL | N | 160 | 100 | ±20 | 2 | 4 | / | / | 3.2 | 3.9 | / | / | TOLL-8L |
| YFWG220N10TL | / | / | YFW G220N10TL | N | 220 | 100 | ±20 | 2 | 4 | / | / | 2.8 | 3.2 | / | / | TOLL-8L |
| YFWG250N10TL | / | / | YFW G250N10TL | N | 250 | 100 | ±20 | 2 | 4 | / | / | 2.2 | 2.8 | / | / | TOLL-8L |
| YFWG290N10TL |
|
|
YFW G290N10TL | N | 290 | 100 | ±20 | 2 | 4 | / | / | 1.6 | 2 | 202 | 11726 | TOLL-8L |
| YFWG300N15TL |
|
|
YFW G300N15TL | N | 300 | 150 | ±20 | 2 | 4 | / | / | 3 | 3.5 | 158 | 11320 | TOLL-8L |
| YFW2300A |
|
|
2300 | N | 4.5 | 20 | ±12 | 0.75 | 1.2 | 22 | 30 | / | / | 4.6 | 310 | SOT-23 |
| YFW2300B |
|
|
2300./A2SHB | N | 2.3 | 20 | ±12 | 0.66 | 0.9 | 43 | 56 | / | / | 2.9 | 280 | SOT-23 |
| YFW2300MI |
|
|
A0SHB | N | 3.3 | 20 | ±12 | 0.75 | 1.2 | 23 | 32 | / | / | 4.6 | 310 | SOT23-3L |
| YFW2302A |
|
|
A2SHB | N | 4,2 | 20 | ±12 | 0.75 | 1.2 | 24 | 32 | / | / | 4.6 | 310 | SOT-23 |
| YFW2302B |
|
|
A2SHB. | N | 3.2 | 20 | ±12 | 0.66 | 0.9 | 43 | 56 | / | / | 2.9 | 280 | SOT-23 |
| YFW2302C | / | / | N | 2.3 | 20 | ±12 | 0.65 | 1.2 | 55 | 65 | / | / | 2.4 | 150 | SOT-23 | |
| YFW2312A | / | / | N | 6.8 | 20 | ±20 | 0.65 | 1 | 16 | 21 | / | / | 11 | 780 | SOT-23 | |
| YFW2312MI |
|
|
S12 | N | 6.8 | 20 | ±20 | 0.5 | 1.2 | 18 | 31.8 | / | / | / | 865 | SOT23-3L |
| YFW2320MI |
|
|
2320 | N | 8 | 20 | ±12 | 0.5 | 1.2 | 8.5 | 12 | / | / | 15 | 625 | SOT23-3L |
| YFW2344CI | / | / | N | 0.7 | 20 | ±12 | / | 1.1 | 80 | 380 | / | / | / | 120 | SOT-523 | |
| YFW3134KM |
|
|
KF | N | 0.75 | 20 | ±12 | 0.35 | 1.1 | 270 | 380 | / | / | / | 79 | SOT-723 |
| YFW1012 |
|
|
NA1 | N | 2.8 | 20 | ±8 | / | 0.95 | / | 380 | / | / | 1.6 | 83 | SOT-523 |
| YFW4153 |
|
|
N | 0.5 | 20 | ±10 | / | 1 | 460 | 630 | / | / | 1.23 | 46 | SOT-523 | |
| BSF20 | / | / | N | 3 | 20 | ±10 | 0.75 | 1.2 | 37 | 59 | / | / | 10 | 300 | SOT-23 | |
| YFW3416 |
|
|
3416 | N | 6.5 | 20 | ±8 | 0.4 | 1.1 | 16 | 22 | / | / | 10 | 1295 | SOT-23 |
| YFW3416MI |
|
|
3416 | N | 6.5 | 20 | ±12 | 0.45 | 1 | 17 | 27 | / | / | 8 | 660 | SOT23-3L |
| YFW15N02S |
|
|
N | 15 | 20 | ±20 | 0.4 | 1.1 | 6.3 | 8 | / | / | 19 | 1458 | SOP-8 | |
| AO3400 |
|
|
A0H | N | 5.8 | 30 | ±12 | 0.7 | 1.4 | 32 | 36 | 29 | 32 | 9.7 | 823 | SOT23-3L |
| YFW3400A | / | / | A09T | N | 6.2 | 30 | ±12 | 0.5 | 1.2 | 24 | 32 | 20 | 28 | 11.5 | 860 | SOT-23 |
| YFW3400B |
|
|
.A09T | N | 5.8 | 30 | ±12 | 0.95 | 1.2 | / | 40 | / | 35 | 3.6 | 1050 | SOT-23 |
| YFW3400C |
|
|
.A09T | N | 4.2 | 30 | ±12 | 0.5 | 1.4 | 36 | 48 | 32 | 42 | 2.6 | 285 | SOT-23 |
| YFW3400MI | / | / | N | 6.2 | 30 | ±12 | / | 1.2 | / | / | 21 | 35 | 11.5 | 530 | SOT23-3L | |
| YFW3404A | / | / | 3404 | N | 7 | 30 | ±12 | 0.8 | 2.2 | 26 | 32 | 24 | 28 | 5.2 | 255 | SOT-23 |
| YFW3404B |
|
|
3404B. | N | 5.8 | 30 | ±20 | 1 | 3 | 31 | 42 | 23 | 30 | 3 | 820 | SOT-23 |
| YFW3404MI |
|
|
3404 | N | 8 | 30 | ±20 | 1.2 | 2.5 | 25 | 32 | 15 | 20 | 11.5 | 860 | SOT23-3L |
| YFW3410MI |
|
|
X10V-34 | N | 13 | 30 | ±20 | 1.2 | 2.5 | 11 | 15 | 11 | 15 | 9.8 | 940 | SOT23-3L |
| YFW4406AS |
|
|
YFW YFW4406AS | N | 12 | 30 | ±20 | 1.2 | 2.5 | 13 | 18 | 8.5 | 12 | 19 | 900 | SOP-8 |
| YFW4406BS |
|
|
YFW YFW4406BS | N | 10 | 30 | ±20 | 1.2 | 2.5 | 28.5 | 38 | 15.6 | 25 | 4.9 | 216 | SOP-8 |
| YFW2306 |
|
|
S6 | N | 3.5 | 30 | ±20 | 1 | 3 | 70 | 94 | 46 | 57 | 4.2 | 555 | SOT-23 |
| YFW3400 | / | / | N | 5.8 | 30 | ±20 | 1.1 | 1.4 | / | / | 22.8 | 28 | 9.7 | 823 | SOT23-3L | |
| 2SK3019 |
|
|
KN | N | 0.1 | 30 | ±20 | / | 1.5 | / | 800 | / | 800 | 15 | 13 | SOT-523 |
| YFW6N03LI |
|
|
6N03LI | N | 6 | 30 | ±12 | 0.5 | 1.5 | 25 | 32 | 20 | 28 | 6 | 572 | SOT23-6L |
| YFW5N04MI |
|
|
5N04 | N | 5 | 40 | ±20 | 1 | 2.5 | 90 | 120 | 65 | 85 | 14 | 596 | SOT23-3L |
| YFW10N04S |
|
|
YFW YFW10N04S | N | 10 | 40 | ±20 | 1 | 2.5 | 18 | 22 | 14.5 | 17 | 9.8 | 1013 | SOP-8 |
| YFW15N04S |
|
|
YFW 15N04S | N | 15 | 40 | ±20 | 1 | 2.5 | 10.5 | 13 | 10.5 | 13 | 10.7 | 1314 | SOP-8 |
| YFW25N04S |
|
|
YFW 25N04S | N | 25.5 | 40 | ±20 | 1 | 2.5 | 6.5 | 10 | 5.5 | 7.5 | 18.8 | 2332 | SOP-8 |
| 2N7002AK |
|
|
NJ | N | 0.3 | 60 | ±20 | 1 | 2.5 | 1900 | 3000 | 1600 | 2500 | 0.27 | 23 | SOT-23 |
| YFW2N7002A | / | / | N | 0.3 | 60 | ±20 | 1.2 | 1.9 | / | / | 1300 | 3000 | 10 | 21 | SOT-23 | |
| YFW2N7002AK | / | / | N | 0.3 | 60 | ±20 | 1.5 | 2.5 | / | / | 1600 | 2500 | 10 | 23 | SOT-23 | |
| 2N7002K | / | / | N | 0.3 | 60 | ±20 | 1.6 | 2.5 | / | / | / | 2000 | 0.8 | 50 | SOT-23 | |
| 2N7002KV |
|
|
72K | N | 0.34 | 60 | ±20 | 1 | 2.5 | 2300 | 5300 | 1500 | 5000 | 30 | 40 | SOT-563 |
| 2N7002KW |
|
|
K72 | N | 0.34 | 60 | ±20 | 1 | 2.5 | 1100 | 5300 | 900 | 5000 | 30 | 40 | SOT-323 |
| 2N7002W | / | / | N | 0.115 | 60 | ±20 | / | 2.5 | / | / | / | 7500 | 20 | 50 | SOT-323 | |
| 2N7002KT |
|
|
72K | N | 0.34 | 60 | ±20 | 1.0 | 2.5 | 2.4 | 3.2 | 2.2 | 3.0 | / | 40 | SOT-523 |
| YFW3N06MI |
|
|
ARDP 78 | N | 3 | 60 | ±20 | 1.2 | 2.5 | 85 | 108 | 80 | 90 | 5.5 | 695 | SOT23-3L |
| YFW3N06 |
|
|
6003 | N | 3 | 60 | ±20 | 0.9 | 2 | 70 | 95 | 60 | 80 | 8.8 | 400 | SOT-23 |
| YFW4N06A |
|
|
A36 | N | 4 | 60 | ±20 | 0.9 | 2 | 85 | 120 | 62 | 85 | 10.27 | 409 | SOT-23 |
| YFW5N06MI |
|
|
NA6-5A | N | 5.8 | 60 | ±20 | 1 | 2.5 | 35 | 50 | 28 | 38 | 19 | 1027 | SOT23-3L |
| YFW6N06LI |
|
|
6N06LI | N | 6 | 60 | ±20 | 1.2 | 2.5 | 40 | 48 | 36 | 40 | 19 | 1027 | SOT23-6L |
| YFW8N06S |
|
|
YFW 8N06S | N | 4.5 | 60 | ±20 | 1 | 2.5 | 45 | 50 | 35 | 40 | 19 | 1027 | SOP-8 |
| YFW10N06S |
|
|
YFW 10N06S | N | 10 | 60 | ±20 | 1.2 | 2.5 | 32 | 38 | 28 | 30 | 12.6 | 1378 | SOP-8 |
| YFW15N06S |
|
|
YFW 15N06S | N | 15 | 60 | ±20 | 1.2 | 2.5 | 18 | 20 | 15 | 18 | 18.8 | 2423 | SOP-8 |
| YFW20N06S |
|
|
YFW 20N06S | N | 20 | 60 | ±20 | 3 | 4 | / | / | 7.8 | 10 | 15 | 4062 | SOP-8 |
| YFW2310A |
|
|
S10 | N | 3 | 60 | ±20 | 0.5 | 2 | 90 | 125 | 85 | 105 | 6 | 247 | SOT-23 |
| YFW6066A |
|
|
6066A | N | 2.1 | 60 | ±20 | 1 | 2.5 | 85 | 110 | / | / | 2.1 | 295 | SOT23-3L |
| YFW3422 |
|
|
A27K | N | 0.2 | 60 | ±20 | 1.1 | 2.1 | 3200 | 4700 | 2800 | 3900 | 0.27 | 11 | SOT23-3L |
| G1003A |
|
|
G1003A | N | 5 | 100 | ±20 | 1 | 3 | / | / | / | 115 | 15.5 | 690 | SOT23-3L |
| YFW1N10 |
|
|
MA3 | N | 1.5 | 100 | ±20 | 1.2 | 2.5 | 460 | 550 | 430 | 500 | 6.47 | 232 | SOT-23 |
| YFW2N10A |
|
|
2N10 | N | 2 | 100 | ±20 | 0.8 | 1.6 | 330 | 450 | 220 | 320 | 3.5 | 362 | SOT-23 |
| YFW3N10B |
|
|
MA4 | N | 3 | 100 | ±20 | 1.5 | 2.5 | / | / | 260 | 310 | 9.7 | 508 | SOT-23 |
| YFW4N10MI | / | / | MA5 | N | 3.8 | 100 | ±20 | 1 | 2.5 | 240 | 280 | 210 | 240 | 9 | 152 | SOT23-3L |
| YFW5N10B | / | / | MA6 | N | 5 | 100 | ±20 | 1.7 | 2.5 | / | / | 105 | 125 | 3.57 | 182 | SOT-23 |
| YFW5N10LI |
|
|
MA6S | N | 5 | 100 | ±20 | 1.2 | 2.5 | 160 | 180 | 110 | 140 | 4.3 | 206.1 | SOT23-6L |
| YFW5N10MI |
|
|
5N10 | N | 5 | 100 | ±20 | 1 | 2.5 | / | 185 | / | 138 | 4 | 200 | SOT23-3L |
| YFW6N10MI |
|
|
1006 | N | 6 | 100 | ±20 | 1.2 | 2.5 | 120 | 145 | 105 | 125 | 3.57 | 582 | SOT23-3L |
| YFW8N10LI |
|
|
N | 8 | 100 | ±20 | 1.2 | 2.5 | 95 | 125 | 80 | 100 | 11.9 | 1100 | SOT23-6L | |
| YFW8N10MI |
|
|
8N10 | N | 8 | 100 | ±20 | 1.2 | 3 | / | 120 | / | 80 | 11.4 | 4960 | SOT23-3L |
| YFW10N10S |
|
|
YFW YFW10N10S | N | 12.3 | 100 | ±20 | 1 | 2.5 | 100 | 140 | 93 | 110 | 12 | 645 | SOP-8 |
| YFW15N10S |
|
|
YFW 15N10S | N | 15 | 100 | ±20 | 1.3 | 2.5 | 8.9 | 10.5 | 6.6 | 7.8 | 50 | 2808 | SOP-8 |
| YFW40N10S |
|
|
YFW YFW40N10S | N | 40 | 100 | ±20 | 1.2 | 2.5 | 24.4 | 30 | 19 | 25 | 16.6 | 1003.9 | SOP-8 |
| YFW1002 |
|
|
1002K | N | 2 | 100 | ±20 | 1.2 | 2.5 | / | / | 185 | 220 | 5.2 | 190 | SOT23-3L |
| YFW6N12MI |
|
|
6N12-AP | N | 6 | 120 | ±20 | 2 | 2.5 | 120 | 200 | 110 | 180 | 11.9 | 1100 | SOT23-3L |
| YFW4N15MI |
|
|
MAB5 | N | 4 | 150 | ±20 | 1 | 3 | 230 | 300 | 220 | 280 | 8 | 235 | SOT23-3L |
| YFW2N20MI |
|
|
MB3-2A | N | 2 | 200 | ±20 | 1 | 3 | / | / | 1400 | 1800 | 12 | 580 | SOT23-3L |
| YFW4N20MI |
|
|
N | 3.8 | 200 | ±20 | 1.2 | 2.5 | 680 | 850 | 450 | 580 | 15 | 900 | SOT23-3L | |
| YFW2311A |
|
|
2311A | P | -8.1 | -12 | ±12 | -0.5 | -1 | 20 | 26 | 18 | 24 | 11.5 | 1100 | SOT-23 |
| YFW2311B |
|
|
2311B | P | -4.8 | -12 | ±12 | -0.4 | -1 | 26 | 32 | / | / | 7.8 | 905 | SOT-23 |
| YFW2311MI |
|
|
20P07 | P | -7 | -12 | ±12 | -0.5 | -1 | 19 | 24 | / | / | 11.5 | 1100 | SOT23-3L |
| YFW2313MI |
|
|
2313 | P | -8 | -12 | ±12 | -0.4 | -1 | 16 | 20 | / | / | 35 | 2700 | SOT23-3L |
| YFW3419 |
|
|
A19T | P | -3.5 | -20 | ±12 | -0.7 | -1.4 | 76 | 95 | 59 | 75 | 5.5 | 512 | SOT23-3L |
| YFW3415A |
|
|
R15 | P | -4.2 | -20 | ±12 | -0.3 | -1 | 37 | 50 | / | / | 17.2 | 1450 | SOT-23 |
| YFW3139KM |
|
|
KD | P | -0.66 | -20 | ±12 | -0.35 | -1.1 | 430 | 520 | / | / | / | 113 | SOT-723 |
| YFW2307MI |
|
|
2307 | P | -7.1 | -20 | ±12 | -0.4 | -1 | 16 | 21 | / | / | 27.3 | 2280 | SOT23-3L |
| YFW2307A |
|
|
2307A | P | -7 | -20 | ±12 | -0.5 | -1.2 | 20 | 25 | / | / | 15.3 | 2000 | SOT-23 |
| YFW2301B |
|
|
A1SHB. | P | -2.3 | -20 | ±12 | -0.4 | -1 | 90 | 112 | / | / | 5.5 | 405 | SOT-23 |
| YFW2301A |
|
|
A1SHB | P | -3.3 | -20 | ±12 | -0.5 | -1.2 | 55 | 80 | / | / | 10.1 | 677 | SOT-23 |
| YFW16P02S |
|
|
P | -16 | -20 | ±12 | -0.5 | -1.2 | 14 | 20 | / | / | 15.3 | 2000 | SOP-8 | |
| DMG1013T |
|
|
PA1 | P | -6 | -20 | ±12 | -0.5 | -1 | 500 | 700 | / | / | 622.4 | 59.76 | SOT-523 |
| YFW9435AS |
|
|
9435 | P | -6 | -30 | ±20 | -1 | -2.5 | 65 | 90 | 43 | 55 | 6.8 | 596 | SOP-8 |
| YFW4435BS |
|
|
P | -9.3 | -30 | ±20 | -1.2 | -2.5 | 25 | 30 | 16 | 20 | 30 | 1550 | SOP-8 | |
| YFW4435AS |
|
|
P | -10.5 | -30 | ±20 | -1 | -2.5 | 18 | 24 | 12 | 16 | 30 | 1800 | SOP-8 | |
| YFW4409AS |
|
|
P | -14 | -30 | ±20 | -1.2 | -2.5 | / | 13.5 | / | 8.7 | 30 | 3448 | SOP-8 | |
| YFW4407 | / | / | P | -12 | -30 | ±20 | -1.5 | -3 | / | / | 11 | 14 | 37.2 | 2076 | SOP-8 | |
| YFW4407BS | / | / | P | -12 | -30 | ±20 | -1.5 | -2.5 | / | / | 11.5 | 16 | 22 | 2130 | SOP-8 | |
| YFW4407AS |
|
|
YFW4407AS | P | -15 | -30 | ±20 | -1 | -2.5 | 10 | 12.5 | 7 | 9 | 59 | 3366 | SOP-8 |
| YFW3409 |
|
|
3409 | P | -5.1 | -30 | ±20 | -0.7 | -1.3 | / | 55 | / | 43 | 6.4 | 826 | SOT23-3L |
| YFW3409MI |
|
|
3409M | P | -12 | -30 | ±20 | -1 | -2.5 | 37 | 54 | 25 | 32 | 9.8 | 930 | SOT23-3L |
| YFW3407 | / | / | P | -4.1 | -30 | ±20 | -1.8 | -3 | / | / | 40.5 | 52 | 14.3 | 700 | SOT23-3L | |
| YFW3407MI |
|
|
3407 | P | -4.8 | -30 | ±20 | -1 | -3 | 68 | 87 | 50 | 60 | 8.6 | 700 | SOT23-3L |
| YFW3407A | / | / | P | -4.8 | -30 | ±20 | -1.5 | -2.5 | / | / | 40 | 55 | 6.8 | 530 | SOT-23 | |
| YFW3401MI |
|
|
X1HV | P | -4.8 | -30 | ±12 | -0.7 | -1.3 | / | 75 | / | 65 | 6.5 | 1050 | SOT23-3L |
| YFW3401B |
|
|
.A09T | P | -4.2 | -30 | ±12 | -0.7 | -1.3 | 51 | 75 | 45 | 65 | 6.3 | 954 | SOT-23 |
| YFW3401A |
|
|
A19T | P | -4.8 | -30 | ±12 | -0.5 | -1.5 | 45 | 55 | 40 | 50 | 8 | 745 | SOT-23 |
| AO3401 |
|
|
B1H | P | -4.2 | -30 | ±12 | -0.7 | -1.3 | 60 | 65 | 52 | 60 | 9.4 | 954 | SOT23-3L |
| YFW3P04A |
|
|
3P04A | P | -3 | -40 | ±20 | -1 | -2.5 | 81 | 100 | 62 | 75 | 6.4 | 620 | SOT-23 |
| YFW5P04MI |
|
|
5P40 | P | -5 | -40 | ±20 | -1 | -2.5 | 85 | 100 | 65 | 70 | 6.4 | 620 | SOT23-3L |
| YFW6P04S |
|
|
YFW 6P04S | P | -6 | -40 | ±20 | -1 | -2.5 | 60 | 65 | / | / | 6.4 | 620 | SOP-8 |
| YFW8P04S |
|
|
YFW 8P04S | P | -8 | -40 | ±20 | -1.2 | -2.5 | / | 46 | / | 32 | 11.5 | 1415 | SOP-8 |
| YFW12P04S |
|
|
YFW 12P04S | P | -12 | -40 | ±20 | -1.6 | -2.5 | 18 | 25 | 14 | 18 | 25 | 2760 | SOP-8 |
| YFW15P04S |
|
|
YFW 15P04S | P | -15.8 | -40 | ±20 | -1 | -2.5 | 16 | 20 | 11 | 15 | 27.9 | 3500 | SOP-8 |
| BSS84 |
|
|
PD | P | -0.52 | -50 | ±20 | -0.9 | -2 | / | / | 1700 | 8000 | 2.5 | 30 | SOT-23 |
| YFW4P05MI |
|
|
4P05M | P | -4.2 | -55 | ±20 | -1 | -2.5 | 125 | 155 | 108 | 125 | 4.6 | 531 | SOT23-3L |
| YFW3P06A |
|
|
S9 | P | -3 | -60 | ±20 | -1 | -2.5 | 158 | 200 | 130 | 150 | 4.6 | 531 | SOT-23 |
| YFW3P06B |
|
|
3906 | P | -2.8 | -60 | ±20 | -1 | -2.5 | 200 | 250 | 165 | 200 | 4.6 | 531 | SOT-23 |
| YFW6P06MI |
|
|
6P06-13 | P | -6 | -60 | ±20 | -1.2 | -2.5 | 100 | 115 | 80 | 90 | 12.1 | 1137 | SOT23-3L |
| YFW01P10 |
|
|
0107 | P | -0.9 | -100 | ±20 | -1 | -2.5 | 560 | 700 | 520 | 650 | 4.5 | 553 | SOT-23 |
| YFW3PMI | / | / | P | -3 | -100 | ±20 | -1.9 | -2.5 | / | / | 260 | 350 | 4.5 | 550 | SOT23-3L | |
| YFW3P10S |
|
|
P | -3 | -100 | ±20 | -1 | -2.5 | 560 | 700 | 450 | 600 | 4.5 | 553 | SOP-8 | |
| YFW8P10S |
|
|
P | -8 | -100 | ±20 | -1.2 | -2.5 | 95 | 120 | 83 | 110 | 20.1 | 1015 | SOP-8 | |
| YFW2P15MI |
|
|
2P15MI | P | -2.7 | -150 | ±20 | -2 | -4 | / | / | 620 | 780 | 10.8 | 706 | SOT23-3L |
| YFW13P20AT |
|
|
P | -13 | -200 | ±20 | -2 | -4 | / | / | 340 | 420 | 44 | 1200 | TO-220AB | |
| YFW13P20AF |
|
|
P | -13 | -200 | ±20 | -2 | -4 | / | / | 340 | 420 | 44 | 1200 | TO-220F | |
| YFW13P20AS |
|
|
P | -13 | -200 | ±20 | -2 | -4 | / | / | 340 | 420 | 44 | 1200 | TO-263 | |
| YFW13P20AD |
|
|
P | -13 | -200 | ±20 | -2 | -4 | / | / | 340 | 420 | 44 | 1200 | TO-252 | |
| YFW9P20AD |
|
|
P | -8.7 | -200 | ±20 | -2 | -4 | / | / | 625 | 750 | 20 | 590 | TO-252 | |
| YFW4P20AT |
|
|
P | -4 | -200 | ±20 | -2 | -4 | / | / | / | 1500 | 20 | 340 | TO-220AB | |
| YFW4P20AF |
|
|
P | -4 | -200 | ±20 | -2 | -4 | / | / | / | 1500 | 20 | 340 | TO-220F | |
| YFW4P20AS |
|
|
P | -4 | -200 | ±20 | -2 | -4 | / | / | / | 1500 | 20 | 340 | TO-263 | |
| YFW4P20AD |
|
|
P | -4 | -200 | ±20 | -2 | -4 | / | / | 1400 | 1700 | 20 | 340 | TO-252 | |
| YFW7P15AMJ | / | / | P | -7 | -150 | ±20 | -2 | -4 | / | / | 620 | 780 | 10.8 | 706 | TO-251 | |
| YFW7P15AD |
|
|
P | -7 | -150 | ±20 | -2 | -4 | / | / | 620 | 780 | 10.8 | 706 | TO-252 | |
| YFW50P10NF |
|
|
P | -50 | -100 | ±20 | -1 | -2.5 | 44 | 62 | 40 | 52 | 40 | 2120 | PDFN5*6-8L | |
| YFW50P10AT |
|
|
P | -50 | -100 | ±20 | -1 | -2.5 | 44 | 62 | 40 | 52 | 40 | 2120 | TO-220AB | |
| YFW50P10AF |
|
|
P | -50 | -100 | ±20 | -1 | -2.5 | 44 | 62 | 40 | 52 | 40 | 2120 | TO-220F | |
| YFW50P10AS |
|
|
P | -50 | -100 | ±20 | -1 | -2.5 | 44 | 62 | 40 | 52 | 40 | 2120 | TO-263 | |
| YFW50P10AD |
|
|
P | -50 | -100 | ±20 | -1 | -2.5 | 44 | 62 | 40 | 52 | 40 | 2120 | TO-252 | |
| YFW40P10AD |
|
|
P | -40 | -100 | ±20 | -1 | -2.5 | 37 | / | 65 | / | 96 | 144 | TO-252 | |
| YFW30P10NF |
|
|
P | -30 | -100 | ±20 | -1.2 | -2.5 | 78 | 110 | 68 | 95 | 44.5 | 3029 | PDFN5*6-8L | |
| YFW30P10AT |
|
|
P | -30 | -100 | ±20 | -1.2 | -2.5 | 86 | 110 | 78 | 95 | 44.5 | 3029 | TO-220AB | |
| YFW30P10AF |
|
|
P | -30 | -100 | ±20 | -1.2 | -2.5 | 86 | 110 | 78 | 95 | 44.5 | 3029 | TO-220F | |
| YFW30P10AS |
|
|
P | -30 | -100 | ±20 | -1.2 | -2.5 | 86 | 110 | 78 | 95 | 44.5 | 3029 | TO-263 | |
| YFW2311B |
|
|
2311B | P | -6.8 | -20 | ±12 | -0.5 | 0.9 | 30 | 45 | / | / | 15 | 740 | SOT-23 |
| YFW2301B |
|
|
S1 | P | -3 | -20 | ±12 | -0.4 | -1 | 90 | 112 | / | / | 5.5 | 405 | SOT-23 |
