| Type | Datasheet | Circuit | Marking | IT(RMS) | ITSM@50Hz | VDRM | VRRM | IGT(1-3) | TJ | Package |
| A | A | V | V | mA | ℃ | |||||
| 重置全部 | / | / | / |
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | / | ||||||||
| BT151B-600 | / | / | 12 | 120 | 600 | 600 | 15 | 125 | TO-220B | |
| BT151B-800 | / | / | 12 | 120 | 800 | 800 | 15 | 125 | TO-220B | |
| BT151B-1000 | / | / | 12 | 120 | 1000 | 1000 | 15 | 125 | TO-220B | |
| TYN840 |
|
|
40 | 460 | 800 | 800 | 35 | 125 | TO-220B | |
| TYN1040 |
|
|
40 | 460 | 1000 | 1000 | 35 | 125 | TO-220B | |
| TYN1240 |
|
|
40 | 460 | 1200 | 1200 | 35 | 125 | TO-220B | |
| BT151D-600 |
|
|
12 | 95 | 600 | 600 | 10 | 125 | TO-252 | |
| BT151D-800 |
|
|
12 | 95 | 800 | 800 | 10 | 125 | TO-252 | |
| BT152D-800 |
|
|
20 | 200 | 800 | 800 | 10 | 125 | TO-252 | |
| BT152D-600 |
|
|
20 | 200 | 600 | 600 | 10 | 125 | TO-252 | |
| FS4040-12M |
|
|
40 | 380 | 1200 | 1200 | 35 | 125 | TO-3P | |
| FS4040-16M |
|
|
40 | 380 | 1600 | 1600 | 35 | 125 | TO-3P | |
| FS5560-12M | / | / | 55 | 550 | 1200 | 1200 | 60 | 125 | TO-3P | |
| FS5560-12N | / | / | 55 | 550 | 1200 | 1200 | 60 | 125 | TO-247 | |
| BCB60-16N |
|
|
60 | 600 | 1600 | 1600 | 60 | 125 | TO-247 | |
| BCB80A |
|
|
80 | 900 | 1200 | 1200 | 60 | 125 | TO-247 | |
| MCR100-8G |
|
|
0.8 | 8 | 600 | 600 | 0.2 | 110 | TO-92 | |
| 2P4MG |
|
|
2 | 20 | 600 | 600 | 0.2 | 110 | TO-92 | |
| 2P4MC |
|
|
2 | 20 | 600 | 600 | 0.2 | 110 | TO-126 |
