Type | Datasheet | Circuit | Marking | Polarity | PCM | IC | VCBO | VCEO | VEBO | hFE | VCE | fT | Package | |
(W) | (A) | (V) | (V) | (V) | Min | Max | (V) | (MHz) | ||||||
重置全部 | / | / | / |
Reset
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
/ | / | / | ||||||||||||
2SC1623 | / | / | NPN | 0.2 | 0.1 | 60 | 50 | 5 | 200 | 400 | 0.3 | 250 | SOT-23 | |
2SC1654 | / | / | NPN | 0.15 | 0.05 | 180 | 160 | 5 | 90 | 400 | 0.3 | 120 | SOT-23 | |
2SC2655 | / | / | NPN | 0.35 | 2 | 50 | 50 | 5 | 70 | 240 | 0.5 | 100 | SOT-23 | |
2SC2873 | / | / | NPN | 0.5 | 2 | 50 | 50 | 5 | 70 | 240 | 0.6 | 120 | SOT-23 | |
2SC3052 | / | / | NPN | 0.15 | 0.2 | 50 | 50 | 6 | 150 | 800 | 0.3 | 180 | SOT-23 | |
2SC3198 | / | / | NPN | 0.5 | 0.15 | 60 | 50 | 5 | 70 | 700 | 0.25 | 80 | SOT-23 | |
2SC3545 | / | / | NPN | 0.15 | 0.05 | 30 | 15 | 3 | 50 | 250 | 0.5 | 1300 | SOT-23 | |
2SD1306 | / | / | NPN | 0.15 | 0.7 | 30 | 15 | 5 | 250 | 800 | 0.5 | 250 | SOT-23 | |
2SD2391 | / | / | NPN | 0.5 | 2 | 60 | 60 | 6 | 120 | 270 | 0.35 | 210 | SOT-23 | |
2SD596 | / | / | NPN | 0.2 | 0.7 | 30 | 25 | 5 | 110 | 400 | 0.6 | 170 | SOT-23 | |
2SD882 | / | / | NPN | 0.5 | 2 | 40 | 30 | 5 | 60 | 400 | 0.5 | 90 | SOT-23 | |
BC817 | / | / | NPN | 0.2 | 0.5 | 50 | 45 | 5 | 100 | 600 | 0.7 | 100 | SOT-23 | |
BC818 | / | / | NPN | 0.2 | 0.5 | 30 | 25 | 5 | 40 | 600 | 0.7 | 100 | SOT-23 | |
BC846 | / | / | NPN | 0.2 | 0.1 | 80 | 65 | 6 | 110 | 800 | 0.5 | 100 | SOT-23 | |
BC847 | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 6 | 110 | 800 | 0.5 | 100 | SOT-23 | |
BC848 | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 110 | 800 | 0.5 | 100 | SOT-23 | |
BC849 | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 110 | 800 | 0.25 | 300 | SOT-23 | |
BC850 | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 110 | 800 | 0.25 | 300 | SOT-23 | |
BCW60 | / | / | NPN | 0.2 | 0.1 | 32 | 32 | 5 | 20 | 630 | 0.05 | 100 | SOT-23 | |
BCX19 | / | / | NPN | 0.225 | 0.5 | 50 | 45 | 5 | 100 | 600 | 0.7 | 100 | SOT-23 | |
C1815 | / | / | NPN | 0.2 | 0.15 | 60 | 50 | 5 | 200 | 400 | 0.25 | 80 | SOT-23 | |
C945 | / | / | NPN | 0.2 | 0.15 | 60 | 50 | 5 | 40 | 400 | 0.3 | 150 | SOT-23 | |
FMMT458 | / | / | NPN | 0.5 | 0.225 | 400 | 400 | 5 | 100 | 300 | 0.5 | 50 | SOT-23 | |
FMMT491 | / | / | NPN | 0.5 | 1 | 80 | 60 | 7 | 100 | 300 | 0.25 | 150 | SOT-23 | |
FMMT493 | / | / | NPN | 0.25 | 1 | 120 | 100 | 5 | 100 | 300 | 0.6 | 150 | SOT-23 | |
FMMT619 | / | / | NPN | 0.35 | 2 | 50 | 50 | 5 | - | 300 | 0.24 | 100 | SOT-23 | |
KTC3265 | / | / | NPN | 0.2 | 0.8 | 35 | 30 | 5 | 10 | 320 | 0.5 | 120 | SOT-23 | |
KTC3880 | / | / | NPN | 0.15 | 0.02 | 40 | 30 | 4 | 40 | 200 | - | 550 | SOT-23 | |
M28S | / | / | NPN | 0.2 | 1 | 40 | 20 | 6 | 290 | 1000 | 0.55 | 100 | SOT-23 | |
MMBT13001 | / | / | NPN | 0.3 | 0.15 | 700 | 420 | 10 | 15 | 25 | 1.05 | 5 | SOT-23 | |
MMBT1616 | / | / | NPN | 0.35 | 1 | 60 | 50 | 6 | 135 | 600 | 0.3 | 100 | SOT-23 | |
MMBT2222A | / | / | NPN | 0.2 | 0.6 | 75 | 40 | 6 | 40 | 300 | 0.3 | 300 | SOT-23 | |
MMBT2222 | / | / | NPN | 0.2 | 0.6 | 75 | 30 | 6 | 40 | 300 | 0.3 | 300 | SOT-23 | |
MMBT2369A | / | / | NPN | 0.2 | 0.2 | 40 | 15 | 4.5 | 20 | 120 | 0.2 | - | SOT-23 | |
MMBT2369 | / | / | NPN | 0.2 | 0.2 | 40 | 15 | 4.5 | 20 | 120 | 0.25 | - | SOT-23 | |
MMBT28S | / | / | NPN | 0.2 | 1 | 40 | 20 | 6 | 40 | 1000 | 0.55 | 100 | SOT-23 | |
MMBT2SC2001 | / | / | PNP | 0.6 | 0.7 | 30 | 25 | 5 | 350 | 450 | 0.6 | 50 | SOT-23 | |
MMBT3904 | / | / | NPN | 0.35 | 0.2 | 60 | 40 | 6 | 30 | 300 | 0.3 | 300 | SOT-23 | |
MMBT4075 | / | / | NPN | 0.1 | 0.15 | 60 | 50 | 5 | 70 | 700 | 0.25 | >80 | SOT-23 | |
MMBT4401 | / | / | NPN | 0.2 | 0.6 | 60 | 40 | 6 | 100 | 300 | 0.4 | 250 | SOT-23 | |
MMBT491A | / | / | NPN | 0.2 | 1 | 40 | 40 | 5 | 200 | 900 | 0.3 | 150 | SOT-23 | |
MMBT495 | / | / | NPN | 0.2 | 1 | 170 | 150 | 5 | 10 | 300 | 0.2 | 100 | SOT-23 | |
MMBT5089 | / | / | NPN | 0.2 | 0.1 | 30 | 25 | 4.5 | 400 | 1200 | 0.5 | 50 | SOT-23 | |
MMBT5550 | / | / | NPN | 0.225 | 0.6 | 160 | 140 | 6 | 60 | 250 | 0.25 | - | SOT-23 | |
MMBT5551-3L | / | / | NPN | 0.35 | 0.6 | 180 | 160 | 6 | 100 | 300 | 0.2 | 100 | SOT-23 | |
MMBT5551 | / | / | NPN | 0.2 | 0.6 | 180 | 160 | 6 | 50 | 300 | 0.15 | 100 | SOT-23 | |
MMBT8050(2A) | / | / | NPN | 0.35 | 2 | 40 | 25 | 6 | 40 | 300 | 0.5 | 100 | SOT-23 | |
MMBT9011 | / | / | NPN | 0.2 | 0.03 | 50 | 30 | 5 | 72 | 190 | 0.3 | 150 | SOT-23 | |
MMBTA05 | / | / | NPN | 0.3 | 0.5 | 60 | 60 | 4 | 100 | 400 | 0.25 | 100 | SOT-23 | |
MMBTA06 | / | / | NPN | 0.35 | 0.5 | 80 | 80 | 4 | 100 | 400 | 0.25 | 100 | SOT-23 | |
MMBTA10 | / | / | NPN | 0.2 | 0.1 | 30 | 25 | 3 | 60 | - | 0.5 | 650 | SOT-23 | |
MMBTA11 | / | / | NPN | 0.2 | 0.1 | 30 | 25 | 3 | 60 | - | 0.5 | 650 | SOT-23 | |
MMBTA14 | / | / | NPN | 0.3 | 0.3 | 30 | 30 | 10 | - | >10000 | 1.5 | 125 | SOT-23 | |
MMBTA42 | / | / | NPN | 0.35 | 0.3 | 300 | 300 | 5 | 60 | 200 | 0.2 | 50 | SOT-23 | |
MMBTA43 | / | / | NPN | 0.35 | 0.5 | 200 | 200 | 5 | 40 | - | 0.5 | 50 | SOT-23 | |
MMBTA44 | / | / | NPN | 0.2 | 0.3 | 500 | 400 | 6 | 40 | 200 | 0.4 | 50 | SOT-23 | |
MMBTH10 | / | / | NPN | 0.2 | 0.05 | 30 | 25 | 3 | 60 | - | 0.5 | 650 | SOT-23 | |
MMBTSC1009 | / | / | NPN | 0.2 | 0.05 | 50 | 30 | 5 | 60 | 180 | 0.3 | 150 | SOT-23 | |
MMBTSC1621 | / | / | NPN | 0.2 | 0.5 | 40 | 15 | 4.5 | 20 | 120 | 0.25 | - | SOT-23 | |
MMBTSC2223 | / | / | NPN | 0.2 | 0.02 | 30 | 20 | 4 | 40 | 180 | 0.3 | 400 | SOT-23 | |
MMBTSC2411 | / | / | NPN | 0.2 | 0.5 | 40 | 32 | 5 | 82 | 390 | 0.4 | 250 | SOT-23 | |
MMBTSC2412 | / | / | NPN | 0.2 | 0.15 | 60 | 50 | 7 | 180 | 390 | 0.4 | 160 | SOT-23 | |
MMBTSC2413 | / | / | NPN | 0.2 | 0.05 | 40 | 25 | 5 | 82 | 180 | 0.3 | 100 | SOT-23 | |
MMBTSC2712 | / | / | NPN | 0.2 | 0.15 | 60 | 50 | 5 | 70 | 700 | 0.25 | 80 | SOT-23 | |
MMBTSC2714 | / | / | NPN | 0.2 | 0.02 | 40 | 30 | 4 | 40 | 200 | - | 550 | SOT-23 | |
MMBTSC2715 | / | / | NPN | 0.2 | 0.05 | 35 | 30 | 4 | 40 | 240 | 0.4 | 100 | SOT-23 | |
MMBTSC2785 | / | / | NPN | 0.2 | 0.15 | 60 | 50 | 5 | 70 | 700 | 0.3 | 300 | SOT-23 | |
MMBTSC2787 | / | / | NPN | 0.2 | 0.03 | 50 | 30 | 5 | 40 | 300 | 0.3 | 150 | SOT-23 | |
MMBTSC3199 | / | / | NPN | 0.2 | 0.15 | 50 | 50 | 5 | 70 | 700 | 0.25 | 80 | SOT-23 | |
MMBTSC3265 | / | / | NPN | 0.2 | 0.8 | 35 | 30 | 5 | 40 | 320 | 0.5 | 120 | SOT-23 | |
MMBTSC3324 | / | / | NPN | 0.2 | 0.1 | 120 | 120 | 5 | 200 | 700 | 0.3 | 100 | SOT-23 | |
MMBTSC3356-3G | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 3000 | SOT-23 | |
MMBTSC3356-7G | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 7000 | SOT-23 | |
MMBTSC3356N-7G | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 7000 | SOT-23 | |
MMBTSC3356 | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 7000 | SOT-23 | |
MMBTSC380 | / | / | NPN | 0.2 | 0.05 | 35 | 30 | 4 | 40 | 240 | 0.4 | 100 | SOT-23 | |
MMBTSC3838 | / | / | NPN | 0.2 | 0.05 | 20 | 11 | 3 | 56 | 240 | 0.5 | 1400 | SOT-23 | |
MMBTSC3875 | / | / | NPN | 0.2 | 0.15 | 60 | 50 | 5 | 70 | 700 | 0.25 | 80 | SOT-23 | |
MMBTSC3876 | / | / | NPN | 0.2 | 0.5 | 35 | 30 | 5 | 25 | 400 | 0.25 | 300 | SOT-23 | |
MMBTSC3928 | / | / | NPN | 0.2 | 0.2 | 50 | 50 | 6 | 70 | 820 | 0.3 | 200 | SOT-23 | |
MMBTSC4226 | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 3000 | SOT-23 | |
MMBTSC5065 | / | / | NPN | 0.2 | 0.03 | 20 | 12 | 3 | 80 | 240 | - | 5000 | SOT-23 | |
MMBTSC5084 | / | / | NPN | 0.2 | 0.08 | 20 | 12 | 3 | 80 | 240 | - | 5000 | SOT-23 | |
MMBTSC5343 | / | / | NPN | 0.2 | 0.15 | 50 | 50 | 5 | 70 | 700 | 0.4 | 180 | SOT-23 | |
MMBTSC5345 | / | / | NPN | 0.2 | 0.02 | 30 | 20 | 4 | 40 | 240 | 0.3 | 550 | SOT-23 | |
MMBTSC930 | / | / | NPN | 0.2 | 0.03 | 30 | 20 | 5 | 40 | 320 | - | 170 | SOT-23 | |
MMBTSD123 | / | / | NPN | 0.2 | 1 | 20 | 15 | 6.5 | - | 150 | 0.3 | 260 | SOT-23 | |
MMBTSD1781 | / | / | NPN | 0.2 | 0.8 | 40 | 32 | 5 | 120 | 390 | 0.4 | 150 | SOT-23 | |
MMBTSD471 | / | / | NPN | 0.2 | 1 | 40 | 30 | 5 | 90 | 400 | 0.5 | 130 | SOT-23 | |
PBSS4140T | / | / | NPN | 0.2 | 1 | 40 | 30 | 5 | 200 | 900 | 0.2 | 150 | SOT-23 | |
PBSS4240 | / | / | NPN | 0.2 | 2 | 40 | 40 | 5 | 80 | 350 | 45 | 230 | SOT-23 | |
S8050 | / | / | NPN | 0.3 | 0.5 | 40 | 25 | 5 | 50 | 350 | 0.6 | 150 | SOT-23 | |
S9013 | / | / | NPN | 0.3 | 0.5 | 40 | 25 | 5 | 120 | 400 | 0.6 | 150 | SOT-23 | |
S9014 | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.3 | 150 | SOT-23 | |
S9018 | / | / | NPN | 0.2 | 0.05 | 30 | 15 | 5 | 105 | 195 | 0.5 | 600 | SOT-23 | |
SS8050 | / | / | NPN | 0.3 | 1.5 | 40 | 25 | 5 | 40 | 350 | 0.5 | 100 | SOT-23 | |
2SC1623W | / | / | NPN | 0.2 | 0.1 | 60 | 50 | 5 | 90 | 700 | 0.3 | 250 | SOT-323 | |
2SC4083 | / | / | NPN | 0.2 | 0.05 | 20 | 11 | 3 | 56 | 700 | 0.5 | 1400 | SOT-323 | |
2SC4097 | / | / | NPN | 0.2 | 0.5 | 40 | 32 | 5 | 82 | 390 | 0.4 | 250 | SOT-323 | |
2SC4116W | / | / | NPN | 0.1 | 0.15 | 60 | 50 | 5 | 70 | 700 | 0.25 | 80 | SOT-323 | |
2SC4177 | / | / | NPN | 0.15 | 0.1 | 60 | 50 | 5 | 70 | 700 | 0.25 | 80 | SOT-323 | |
2SC5876W | / | / | NPN | 0.2 | 0.5 | 60 | 60 | 6 | 120 | 390 | 0.3 | 300 | SOT-323 | |
BC817W | / | / | NPN | 0.2 | 0.5 | 50 | 45 | 5 | 100 | 600 | 0.7 | 100 | SOT-323 | |
BC846AW | / | / | NPN | 0.2 | 0.1 | 80 | 65 | 6 | 110 | 220 | 0.25 | 100 | SOT-323 | |
BC846BW | / | / | NPN | 0.2 | 0.1 | 80 | 65 | 6 | 200 | 450 | 0.25 | 100 | SOT-323 | |
BC846CW | / | / | NPN | 0.2 | 0.1 | 80 | 65 | 6 | 420 | 800 | 0.25 | 100 | SOT-323 | |
BC847AW | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 6 | 110 | 220 | 0.25 | 100 | SOT-323 | |
BC847BW | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 6 | 200 | 450 | 0.25 | 100 | SOT-323 | |
BC847CW | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 6 | 420 | 800 | 0.25 | 100 | SOT-323 | |
BC848AW | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 110 | 220 | 0.25 | 100 | SOT-323 | |
BC848BW | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 200 | 450 | 0.25 | 100 | SOT-323 | |
BC848CW | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 420 | 800 | 0.25 | 100 | SOT-323 | |
BC849AW | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 110 | 220 | 0.25 | 100 | SOT-323 | |
BC849BW | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 200 | 450 | 0.25 | 100 | SOT-323 | |
BC849CW | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 420 | 800 | 0.25 | 100 | SOT-323 | |
BC850AW | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 110 | 220 | 0.25 | 100 | SOT-323 | |
BC850BW | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.25 | 100 | SOT-323 | |
BC850CW | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 420 | 800 | 0.25 | 100 | SOT-323 | |
MMBT3904W | / | / | NPN | 0.2 | 0.2 | 60 | 40 | 6 | 100 | 300 | 0.3 | 300 | SOT-323 | |
MMBT4401W | / | / | NPN | 0.2 | 0.6 | 60 | 40 | 6 | 100 | 300 | 0.4 | 250 | SOT-323 | |
MMBT5551W | / | / | NPN | 0.2 | 0.6 | 180 | 160 | 6 | 80 | 300 | 0.2 | 100 | SOT-323 | |
MMBTA06W | / | / | NPN | 0.5 | 0.5 | 80 | 80 | 4 | 100 | 400 | 0.25 | 100 | SOT-323 | |
MMBTA42W | / | / | NPN | 0.35 | 0.3 | 300 | 300 | 5 | 60 | 200 | 0.2 | 50 | SOT-323 | |
MMBTH10W | / | / | NPN | 0.2 | 0.05 | 30 | 25 | 3 | 60 | - | 0.5 | 650 | SOT-323 | |
MMBTSC3356W | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 7 | SOT-323 | |
MMBTSC3356W-7G | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 7000 | SOT-323 | |
MMBTSC4081W | / | / | NPN | 0.2 | 0.15 | 60 | 50 | 7 | 120 | 560 | 0.4 | 180 | SOT-323 | |
MMBTSC4226W | / | / | NPN | 0.15 | 0.1 | 20 | 12 | 3 | 40 | 250 | 0.5 | 3 | SOT-323 | |
MMBTSC4226W-7G | / | / | NPN | 0.15 | 0.1 | 20 | 12 | 3 | 40 | 250 | 0.5 | 7000 | SOT-323 | |
S8050W | / | / | NPN | 0.3 | 0.5 | 40 | 25 | 5 | 120 | 400 | 0.6 | 150 | SOT-323 | |
S8050W-0.8A | / | / | NPN | 0.25 | 0.8 | 40 | 25 | 5 | 120 | 400 | 0.6 | 150 | SOT-323 | |
S9013W | / | / | NPN | 0.2 | 0.5 | 40 | 25 | 5 | 120 | 400 | 0.6 | 150 | SOT-323 | |
S9014W | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 1000 | 0.3 | 150 | SOT-323 | |
S9018W | / | / | NPN | 0.2 | 0.05 | 30 | 15 | 5 | 105 | 195 | 0.5 | 600 | SOT-323 | |
SS8050W | / | / | NPN | 0.2 | 1.5 | 40 | 25 | 5 | 120 | 400 | 0.5 | 100 | SOT-323 | |
2SC5585DW | / | / | NPN | 0.15 | 0.5 | 15 | 12 | 6 | 270 | 680 | 0.25 | 320 | SOT-363 | |
BC817DW | / | / | NPN | 0.2 | 0.5 | 50 | 45 | 5 | 100 | 600 | 0.7 | 100 | SOT-363 | |
2SC1623T | / | / | NPN | 0.2 | 0.1 | 60 | 50 | 5 | 90 | 700 | 0.3 | 250 | SOT-523 | |
2SC4617 | / | / | NPN | 0.15 | 0.15 | 60 | 50 | 7 | 120 | 560 | 0.4 | 180 | SOT-523 | |
2SC4738 | / | / | NPN | 0.1 | 0.15 | 60 | 50 | 5 | 120 | 700 | 0.25 | 80 | SOT-523 | |
2SC5585 | / | / | NPN | 0.15 | 0.5 | 15 | 12 | 6 | 270 | 680 | 0.25 | 320 | SOT-523 | |
BC846AT | / | / | NPN | 0.2 | 0.1 | 80 | 65 | 5 | 110 | 220 | 0.6 | 100 | SOT-523 | |
BC846BT | / | / | NPN | 0.2 | 0.1 | 80 | 65 | 6 | 200 | 450 | 0.6 | 100 | SOT-523 | |
BC846CT | / | / | NPN | 0.2 | 0.1 | 80 | 65 | 6 | 420 | 800 | 0.6 | 100 | SOT-523 | |
BC846E | / | / | NPN | 0.15 | 0.1 | 80 | 65 | 6 | 110 | 220 | 0.25 | 300 | SOT-523 | |
BC847AT | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 110 | 220 | 0.6 | 100 | SOT-523 | |
BC847BT | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.6 | 100 | SOT-523 | |
BC847CT | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 6 | 420 | 800 | 0.6 | 100 | SOT-523 | |
BC847E | / | / | NPN | 0.15 | 0.1 | 50 | 45 | 6 | 110 | 220 | 0.25 | 300 | SOT-523 | |
BC848AT | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 110 | 220 | 0.6 | 100 | SOT-523 | |
BC848BT | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 200 | 450 | 0.6 | 100 | SOT-523 | |
BC848CT | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 420 | 800 | 0.6 | 100 | SOT-523 | |
BC848E | / | / | NPN | 0.15 | 0.1 | 30 | 30 | 5 | 110 | 220 | 0.25 | 300 | SOT-523 | |
BC849AT | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 110 | 200 | 0.6 | 100 | SOT-523 | |
BC849BT | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 420 | 800 | 0.6 | 100 | SOT-523 | |
BC849CT | / | / | NPN | 0.2 | 0.1 | 30 | 30 | 5 | 200 | 450 | 0.6 | 100 | SOT-523 | |
BC849E | / | / | NPN | 0.15 | 0.1 | 30 | 30 | 5 | 110 | 220 | 0.25 | 300 | SOT-523 | |
BC850AT | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 110 | 220 | 0.6 | 100 | SOT-523 | |
BC850BT | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.6 | 100 | SOT-523 | |
BC850CT | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 420 | 800 | 0.6 | 100 | SOT-523 | |
BC850E | / | / | NPN | 0.15 | 0.1 | 50 | 45 | 5 | 110 | 220 | 0.25 | 300 | SOT-523 | |
MMBT2222AE | / | / | NPN | 0.15 | 0.6 | 75 | 40 | 6 | 40 | - | 0.3 | 300 | SOT-523 | |
MMBT2222E | / | / | NPN | 0.15 | 0.6 | 60 | 30 | 5 | 30 | - | 0.4 | 300 | SOT-523 | |
MMBT3904E | / | / | NPN | 0.15 | 0.2 | 60 | 40 | 6 | 100 | 300 | 0.3 | 300 | SOT-523 | |
MMBT3904T | / | / | NPN | 0.15 | 0.2 | 60 | 40 | 6 | 100 | 300 | 0.2 | 300 | SOT-523 | |
MMBTSC1815E | / | / | NPN | 0.15 | 0.15 | 60 | 50 | 5 | 70 | 140 | 0.25 | 80 | SOT-523 | |
MMBTSC2712T | / | / | NPN | 0.15 | 0.15 | 60 | 50 | 5 | 70 | 700 | 0.25 | 80 | SOT-523 | |
MMBTSC3356T-3G | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 3000 | SOT-523 | |
MMBTSC3356T-7G | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 7000 | SOT-523 | |
MMBTSC3356W-3G | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 3000 | SOT-523 | |
MMBTSC4075E | / | / | NPN | 0.15 | 0.15 | 60 | 50 | 7 | 70 | 700 | 0.25 | 80 | SOT-523 | |
MMBTSC4627E | / | / | NPN | 0.125 | 0.015 | 30 | 20 | 3 | 40 | 110 | 0.5 | 450 | SOT-523 | |
S8050E | / | / | NPN | 0.3 | 0.5 | 40 | 25 | 5 | 120 | 400 | 0.6 | 150 | SOT-523 | |
S8050T | / | / | NPN | 0.3 | 0.5 | 40 | 25 | 5 | 200 | 350 | 0.5 | 150 | SOT-523 | |
S8050T-0.8A | / | / | NPN | 0.2 | 0.8 | 40 | 25 | 5 | 200 | 350 | 0.6 | 150 | SOT-523 | |
S9014T | / | / | NPN | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.3 | 150 | SOT-523 | |
S9018T | / | / | NPN | 0.2 | 0.05 | 30 | 15 | 5 | 105 | 195 | 0.5 | 600 | SOT-523 | |
MMBT5551T | / | / | NPN | 0.2 | 0.6 | 180 | 160 | 6 | 50 | 300 | 0.15 | 100 | SOT-523 | |
MMBT3904M | / | / | NPN | 0.2 | 0.2 | 60 | 40 | 5 | 100 | 300 | 0.3 | 300 | SOT-723 | |
YFW13001 | / | / | NPN | 0.75 | 0.3 | 700 | 450 | 9 | 15 | 30 | 0.4 | >8 | SOT-89 | |
YFW13002 | / | / | NPN | 0.6 | 0.2 | 700 | 400 | 9 | 20 | 40 | 0.5 | 4 | SOT-89 | |
YFW13003 | / | / | NPN | 0.8 | 1.5 | 800 | 430 | 9 | 6 | 40 | 0.5 | 4 | SOT-89 | |
PXT2222A | / | / | NPN | 0.625 | 0.6 | 75 | 40 | 6 | 100 | 300 | 0.3 | 250 | SOT-89 | |
PXT3904 | / | / | NPN | 0.5 | 0.2 | 60 | 40 | 6 | 100 | 300 | 0.3 | 300 | SOT-89 | |
CXT5551 | / | / | NPN | 0.5 | 0.6 | 18 | 160 | 6 | 80 | 250 | 0.15 | 100 | SOT-89 | |
2N6718 | / | / | NPN | 1 | 1 | 100 | 100 | 5 | 50 | 250 | 0.5 | 500 | SOT-89 | |
2SC1766 | / | / | NPN | 0.5 | 2 | 50 | 50 | 5 | 82 | 390 | 0.5 | 120 | SOT-89 | |
2SC2383 | / | / | NPN | 0.5 | 1 | 160 | 160 | 6 | 100 | 320 | 1 | 20 | SOT-89 | |
2SC2655 | / | / | NPN | 0.5 | 2 | 50 | 50 | 5 | 70 | 240 | 0.5 | 100 | SOT-89 | |
2SC2873 | / | / | NPN | 0.5 | 2 | 50 | 50 | 5 | 70 | 240 | 0.5 | 120 | SOT-89 | |
2SC2881 | / | / | NPN | 0.5 | 0.8 | 120 | 120 | 5 | 80 | 160 | 1 | 120 | SOT-89 | |
2SC2883 | / | / | NPN | 0.5 | 1.5 | 30 | 30 | 5 | 100 | 320 | 2 | 120 | SOT-89 | |
2SC2884 | / | / | NPN | 0.5 | 0.8 | 35 | 30 | 5 | 100 | 320 | 0.5 | 120 | SOT-89 | |
2SC3357 | / | / | NPN | 1.2 | 0.1 | 20 | 12 | 3 | 50 | 300 | 10 | - | SOT-89 | |
2SC3650 | / | / | NPN | 0.5 | 1.2 | 30 | 25 | 15 | 800 | 3200 | 0.5 | 150 | SOT-89 | |
2SC4132 | / | / | NPN | 0.5 | 2 | 120 | 120 | 5 | 120 | 270 | 0.5 | 80 | SOT-89 | |
2SC4373 | / | / | NPN | 0.5 | 0.8 | 120 | 120 | 5 | 80 | 240 | 0.5 | 120 | SOT-89 | |
2SC4374 | / | / | NPN | 0.5 | 0.4 | 80 | 80 | 5 | 70 | 240 | 0.4 | 100 | SOT-89 | |
2SC4375 | / | / | NPN | 0.5 | 1.5 | 30 | 30 | 5 | 100 | 320 | 2 | 120 | SOT-89 | |
2SC4378 | / | / | NPN | 1 | 1 | 80 | 60 | 5 | 30 | - | 0.5 | 150 | SOT-89 | |
2SC4379 | / | / | NPN | 0.5 | 2 | 50 | 50 | 5 | 70 | 240 | 0.5 | 120 | SOT-89 | |
2SC4541 | / | / | NPN | 1 | 3 | 80 | 50 | 6 | 120 | 400 | 0.5 | 100 | SOT-89 | |
2SC4548 | / | / | NPN | 0.5 | 0.2 | 400 | 400 | 5 | 60 | 200 | 0.6 | 70 | SOT-89 | |
2SC4672 | / | / | NPN | 2 | 3 | 60 | 50 | 6 | 82 | 270 | 0.35 | 210 | SOT-89 | |
2SC5824 | / | / | NPN | 0.5 | 3 | 60 | 60 | 6 | 120 | 390 | 1 | 200 | SOT-89 | |
2SD1005 | / | / | NPN | 0.5 | 1 | 100 | 80 | 5 | 25 | 400 | 0.5 | 160 | SOT-89 | |
2SD1006 | / | / | NPN | 2 | 0.7 | 100 | 100 | 5 | 90 | 400 | 0.6 | 90 | SOT-89 | |
2SD1007 | / | / | NPN | 2 | 0.7 | 120 | 120 | 5 | 90 | 400 | 0.6 | 90 | SOT-89 | |
2SD1368 | / | / | NPN | 1 | 1 | 100 | 50 | 6 | 160 | 500 | 0.3 | 100 | SOT-89 | |
2SD1615 | / | / | NPN | 2 | 1 | 60 | 50 | 6 | 135 | 600 | 0.3 | 160 | SOT-89 | |
2SD1616A | / | / | NPN | 0.5 | 1 | 120 | 60 | 6 | 135 | 600 | 0.3 | 100 | SOT-89 | |
2SD1616 | / | / | NPN | 0.5 | 1 | 60 | 50 | 6 | 135 | 600 | 0.3 | 100 | SOT-89 | |
2SD1623 | / | / | NPN | 1.3 | 2 | 60 | 50 | 6 | 100 | 560 | 0.4 | 150 | SOT-89 | |
2SD1624 | / | / | NPN | 0.5 | 3 | 60 | 50 | 6 | 100 | 560 | 0.7 | 150 | SOT-89 | |
2SD1898 | / | / | NPN | 0.5 | 1 | 100 | 80 | 5 | 82 | 390 | <0.4 | 100 | SOT-89 | |
2SD2098 | / | / | NPN | 0.5 | 5 | 50 | 20 | 6 | 120 | 390 | <1 | 150 | SOT-89 | |
2SD2150 | / | / | NPN | 0.5 | 3 | 40 | 20 | 6 | 180 | 560 | 0.5 | 290 | SOT-89 | |
2SD2391 | / | / | NPN | 0.5 | 2 | 60 | 60 | 6 | 120 | 270 | 0.35 | 120 | SOT-89 | |
2SD669 | / | / | NPN | 0.75 | 1.5 | 180 | 160 | 5 | 60 | 320 | 1 | 140 | SOT-89 | |
2SD874 | / | / | NPN | 1 | 1 | 60 | 50 | 5 | 85 | 340 | 0.4 | 200 | SOT-89 | |
2SD882H | / | / | NPN | 0.5 | 3 | 70 | 70 | 6 | 60 | 400 | 0.5 | 50 | SOT-89 | |
2SD965 | / | / | NPN | 0.75 | 5 | 40 | 20 | 7 | 230 | 600 | 1 | 150 | SOT-89 | |
PXT8050 | / | / | NPN | 0.625 | 1.5 | 40 | 25 | 6 | 120 | 300 | 0.5 | 100 | SOT-89 | |
PXT8050 | / | / | NPN | 0.5 | 1.5 | 40 | 25 | 5 | 120 | 400 | 0.5 | 100 | SOT-89 | |
BC868 | / | / | NPN | 0.5 | 1 | 32 | 20 | 5 | 85 | 375 | <0.5 | 40 | SOT-89 | |
BCX54 | / | / | NPN | 0.5 | 1 | 45 | 45 | 5 | 63 | 250 | 0.5 | 130 | SOT-89 | |
BCX55 | / | / | NPN | 0.5 | 1 | 60 | 60 | 5 | 63 | 250 | 0.5 | 130 | SOT-89 | |
BCX56 | / | / | NPN | 0.5 | 1 | 100 | 80 | 5 | 63 | 250 | 0.5 | 130 | SOT-89 | |
FCX495 | / | / | NPN | 1 | 1 | 170 | 150 | 5 | 100 | 300 | 0.2 | 100 | SOT-89 | |
MMBT4401 | / | / | NPN | 0.5 | 0.6 | 60 | 40 | 6 | 100 | 300 | 0.4 | 250 | SOT-89 | |
MMBTSC3356 | / | / | NPN | 0.2 | 0.1 | 20 | 12 | 3 | 50 | 250 | - | 7 | SOT-89 | |
MPSA42 | / | / | NPN | 0.35 | 0.3 | 300 | 300 | 5 | 60 | 200 | 0.2 | 50 | SOT-89 | |
MPSA44 | / | / | NPN | 0.625 | 0.3 | 500 | 400 | 6 | 40 | - | 0.5 | - | SOT-89 | |
PBSS4540X | / | / | NPN | 0.55 | 4 | 40 | 40 | 6 | >300 | 0.12 | 70 | SOT-89 | ||
S9013 | / | / | NPN | 0.3 | 0.5 | 40 | 25 | 5 | 120 | 400 | 0.6 | 150 | SOT-89 | |
S9014 | / | / | NPN | 0.5 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.3 | 150 | SOT-89 | |
SS8050 | / | / | NPN | 0.3 | 1.5 | 40 | 25 | 5 | 40 | 400 | 0.5 | 100 | SOT-89 | |
BC817DPN | / | / | NPN+PNP | 0.2 | 0.5 | 50 | 45 | 5 | 160 | 400 | 0.7 | 100 | SOT23-6L | |
BC846AF | / | / | NPN+NPN | 0.2 | 0.1 | 80 | 65 | 6 | 110 | 220 | 0.5 | 100 | SOT23-6L | |
BC846BF | / | / | NPN+NPN | 0.2 | 0.1 | 80 | 65 | 6 | 200 | 450 | 0.5 | 100 | SOT23-6L | |
BC846CF | / | / | NPN+NPN | 0.2 | 0.1 | 80 | 65 | 6 | 420 | 800 | 0.5 | 100 | SOT23-6L | |
MMDT2222AF | / | / | NPN+NPN | 0.3 | 0.6 | 75 | 40 | 6 | 100 | 300 | 0.3 | 300 | SOT23-6L | |
MMDT3946F | / | / | NPN+PNP | 0.3 | 0.2 | 40 | 40 | 5 | 100 | 300 | 0.4 | 250 | SOT23-6L | |
MMDT5551SF | / | / | NPN+NPN | 0.3 | 0.6 | 180 | 160 | 6 | 100 | 300 | 0.2 | 100 | SOT23-6L | |
BC817PN | / | / | NPN+PNP | 0.2 | 0.5 | 50 | 45 | 5 | 160 | 400 | 0.7 | 100 | SOT-363 | |
BC846DW | / | / | NPN+NPN | 0.2 | 0.1 | 80 | 65 | 6 | 110 | 600 | 0.1 | 100 | SOT-363 | |
BC846PN | / | / | NPN+PNP | 0.2 | 0.1 | 80 | 65 | 6 | 200 | 450 | 0.25 | 100 | SOT-363 | |
BC847APN | / | / | NPN+PNP | 0.2 | 0.1 | 50 | 45 | 5 | 110 | 220 | 0.6 | 100 | SOT-363 | |
BC847BPN | / | / | NPN+PNP | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.6 | 100 | SOT-363 | |
BC847CPN | / | / | NPN+PNP | 0.2 | 0.1 | 50 | 45 | 5 | 420 | 800 | 0.6 | 100 | SOT-363 | |
BC847DW | / | / | NPN+NPN | 0.2 | 0.1 | 50 | 45 | 6 | 110 | 800 | 0.6 | 300 | SOT-363 | |
BC847PN | / | / | NPN+PNP | 0.2 | 0.1 | 50 | 45 | 6 | 200 | 450 | 0.6 | 300 | SOT-363 | |
DMMT3904W | / | / | NPN+NPN | 0.2 | 0.2 | 60 | 40 | 5 | 100 | 300 | 0.2 | 300 | SOT-363 | |
MMBT4601PN | / | / | NPN+PNP | 0.38 | 0.15 | 60 | 50 | 6 | 120 | 560 | 0.4 | 180 | SOT-363 | |
MMBT5541DW | / | / | PNP+NPN | 0.2 | 0.2 | 180 | 160 | 6 | 100 | 300 | 0.2 | 100 | SOT-363 | |
MMBTSC4201DW | / | / | NPN+NPN | 0.25 | 0.1 | 50 | 45 | 6 | 200 | 450 | 0.2 | 100 | SOT-363 | |
MMDT2222ADW | / | / | NPN+NPN | 0.2 | 0.6 | 75 | 40 | 6 | 100 | 300 | 0.3 | 300 | SOT-363 | |
MMDT2227DW | / | / | NPN+PNP | 0.2 | 0.6,-06 | 75,-60 | 40,-60 | 6,-5 | 100 | 300 | 0.3 | 300 | SOT-363 | |
MMDT3052DW | / | / | NPN+NPN | 0.15 | 0.2 | 50 | 50 | 6 | 120 | 700 | 0.3 | 200 | SOT-363 | |
MMDT3904DW | / | / | NPN+NPN | 0.2 | 0.2 | 60 | 40 | 5 | 100 | 300 | 0.2 | 300 | SOT-363 | |
MMDT3946DW | / | / | NPN+PNP | 0.2 | 0.2 | 60,-40 | 40,-40 | 5,-5 | 100 | 300 | 0.3 | 300 | SOT-363 | |
MMDT4401DW | / | / | NPN+NPN | 0.2 | 0.6 | 60 | 40 | 6 | 100 | 300 | 0.75 | 250 | SOT-363 | |
MMDT4501DW | / | / | NPN+NPN | 0.38 | 0.15 | 60 | 50 | 7 | 120 | 560 | 0.4 | 180 | SOT-363 | |
MMDT5551DW | / | / | NPN+NPN | 0.2 | 0.2 | 180 | 160 | 6 | 100 | 300 | 0.2 | 100 | SOT-363 | |
MMDT9014DW | / | / | NPN+NPN | 0.2 | 0.1 | 50 | 45 | 5 | 300 | 400 | 0.3 | 150 | SOT-363 | |
UMX1N | / | / | NPN+NPN | 0.15 | 0.15 | 60 | 50 | 7 | 120 | 560 | 0.4 | 80 | SOT-363 | |
UMX3N | / | / | NPN+NPN | 0.15 | 0.15 | 60 | 50 | 7 | 120 | 560 | 0.4 | 180 | SOT-363 | |
BC846BV | / | / | NPN+NPN | 0.15 | 0.1 | 80 | 65 | 6 | 200 | 450 | 0.5 | 100 | SOT-563 | |
BC847BV | / | / | NPN+NPN | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.6 | 100 | SOT-563 | |
BC847BVN | / | / | NPN+PNP | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.6 | 100 | SOT-563 | |
EMX1 | / | / | NPN+NPN | 0.15 | 0.15 | 60 | 50 | 7 | 120 | 560 | 0.4 | 100 | SOT-563 | |
EMZ7 | / | / | NPN+PNP | 0.15 | 0.5 | 15 | 12 | 6 | 270 | 680 | 0.25 | 320 | SOT-563 | |
MMDT222AV | / | / | NPN+NPN | 0.2 | 0.6 | 75 | 40 | 6 | 100 | 300 | 0.3 | 300 | SOT-563 | |
MMDT3946V | / | / | NPN+PNP | 0.2 | 0.2 | 60-40 | 40-40 | 5 | 100 | 300 | 0.3 | 300 | SOT-563 | |
MMDT5551V | / | / | NPN+NPN | 0.2 | 0.2 | 180 | 160 | 6 | 100 | 300 | 0.2 | 100 | SOT-563 | |
S8050V | / | / | NPN | 0.3 | 0.5 | 40 | 25 | 5 | 50 | 350 | 0.6 | 150 | SOT-563 | |
MMBT4401 | / | / | PNP | 0.3 | 0.6 | 60 | 40 | 6 | 100 | 300 | 0.4 | 250 | SOT-23 | |
2SA1020 | / | / | PNP | 0.3 | -2 | -50 | -50 | -5 | 70 | 240 | -0.5 | 100 | SOT-23 | |
2SA1213 | / | / | PNP | 0.3 | -2 | -50 | -50 | -5 | 70 | 240 | -0.5 | 100 | SOT-23 | |
2SA1362 | / | / | PNP | 0.2 | -0.8 | -15 | -15 | -5 | 120 | 400 | -0.2 | 120 | SOT-23 | |
2SA812 | / | / | PNP | 0.2 | -0.1 | -60 | -50 | -5 | 90 | 600 | -0.3 | 180 | SOT-23 | |
2SB1197 | / | / | PNP | 0.2 | -0.8 | -40 | -32 | -5 | 82 | 390 | -0.5 | 200 | SOT-23 | |
2SB709A | / | / | PNP | 0.2 | -0.1 | -45 | 45 | -7 | 200 | 350 | -0.5 | 60 | SOT-23 | |
2SB772 | / | / | PNP | 1 | 3 | 40 | 30 | 5 | 60 | 400 | 0.5 | 80 | SOT-23 | |
BC807-16 | / | / | PNP | 0.3 | -0.5 | -50 | -45 | -5 | 100 | 250 | -0.7 | 100 | SOT-23 | |
BC807-25 | / | / | PNP | 0.3 | -0.5 | -50 | -45 | -5 | 160 | 400 | -0.7 | 100 | SOT-23 | |
BC807-40 | / | / | PNP | 0.3 | -0.5 | -50 | -45 | -5 | 250 | 630 | -0.7 | 100 | SOT-23 | |
BC808 | / | / | PNP | 0.2 | -0.5 | -30 | 25 | -5 | 40 | 600 | -0.7 | 100 | SOT-23 | |
BC856 | / | / | PNP | 0.2 | -0.1 | -80 | 65 | -5 | 125 | 800 | -0.3 | 100 | SOT-23 | |
BC857 | / | / | PNP | 0.2 | -0.1 | -50 | 45 | -5 | 125 | 800 | -0.3 | 100 | SOT-23 | |
BC858 | / | / | PNP | 0.2 | -0.1 | -30 | 30 | -5 | 125 | 800 | -0.3 | 100 | SOT-23 | |
BC859 | / | / | PNP | 0.2 | -0.1 | -30 | 30 | -5 | 125 | 800 | -0.3 | 100 | SOT-23 | |
BC860 | / | / | PNP | 0.2 | -0.1 | -50 | 45 | -5 | 125 | 800 | -0.3 | 100 | SOT-23 | |
BCW30 | / | / | PNP | 0.2 | -0.1 | -32 | 32 | -5 | 215 | 500 | -0.3 | 100 | SOT-23 | |
BCW61 | / | / | PNP | 0.2 | -0.1 | -32 | 32 | -5 | 30 | 630 | -0.12 | 100 | SOT-23 | |
BCW68 | / | / | PNP | 0.2 | -0.8 | -60 | 45 | -5 | 35 | 630 | -0.3 | 200 | SOT-23 | |
BCX42 | / | / | PNP | 0.33 | 0.8 | 125 | 125 | 5 | - | >63 | 0.9 | 150 | SOT-23 | |
FMMT591 | / | / | PNP | 1 | 0.25 | 80 | 60 | 5 | 100 | 300 | 0.6 | 150 | SOT-23 | |
FMMT593 | / | / | PNP | 0.25 | 1 | 120 | 100 | 5 | 100 | 300 | 0.3 | 50 | SOT-23 | |
FMMT718 | / | / | PNP | 0.35 | -1.5 | -20 | -20 | -7 | 300 | - | -0.22 | 150 | SOT-23 | |
MMBT2907A | / | / | PNP | 0.35 | -0.6 | -60 | 60 | -5 | 50 | 300 | -0.4 | 200 | SOT-23 | |
MMBT2907 | / | / | PNP | 0.35 | -0.6 | -60 | 40 | -5 | 30 | 300 | -0.4 | 200 | SOT-23 | |
MMBT3906 | / | / | PNP | 0.35 | -0.2 | -40 | 40 | -6 | 30 | 300 | -0.3 | 300 | SOT-23 | |
MMBT4403 | / | / | PNP | 0.2 | -0.6 | -40 | 40 | -5 | 100 | 300 | -0.4 | 200 | SOT-23 | |
MMBT5087 | / | / | PNP | 0.2 | -0.1 | -50 | 50 | -3 | 250 | 800 | -0.3 | 40 | SOT-23 | |
MMBT5400 | / | / | PNP | 0.2 | -0.6 | -130 | -120 | -5 | 40 | 180 | -0.5 | 100 | SOT-23 | |
MMBT5401 | / | / | PNP | 0.2 | -0.6 | -160 | -150 | -5 | 50 | 350 | -0.5 | 100 | SOT-23 | |
MMBT589 | / | / | PNP | 0.31 | 1 | -50 | -30 | -5 | 100 | 300 | -0.3 | 100 | SOT-23 | |
MMBT591A | / | / | PNP | 0.2 | 1 | -40 | 40 | -5 | 160 | 800 | -0.2 | 150 | SOT-23 | |
MMBT8550(2A) | / | / | PNP | 0.35 | 2 | -40 | 25 | -6 | 40 | 300 | -0.5 | 100 | SOT-23 | |
MMBTA55 | / | / | PNP | 0.225 | 0.5 | 60 | 60 | 4 | 100 | 400 | 0.25 | 50 | SOT-23 | |
MMBTA56 | / | / | PNP | 0.2 | -0.5 | -80 | - | -4 | 100 | - | -0.25 | 50 | SOT-23 | |
MMBTA92 | / | / | PNP | 0.35 | -0.3 | -300 | 300 | -5 | 100 | 200 | -0.2 | 50 | SOT-23 | |
MMBTA93 | / | / | PNP | 0.35 | -0.5 | -200 | 200 | -5 | 25 | 200 | -0.5 | 50 | SOT-23 | |
MMBTA94 | / | / | PNP | 0.2 | -0.3 | -400 | 400 | -6 | 25 | 100 | -0.5 | - | SOT-23 | |
MMBTSA1015 | / | / | PNP | 0.2 | -0.15 | -50 | 50 | -5 | 25 | 400 | -0.3 | 80 | SOT-23 | |
MMBTSA1036 | / | / | PNP | 0.2 | -0.5 | -40 | 32 | -5 | 82 | 390 | -0.6 | 200 | SOT-23 | |
MMBTSA1037 | / | / | PNP | 0.2 | -0.15 | -60 | - | - | 120 | 560 | -0.5 | 120 | SOT-23 | |
MMBTSA1162 | / | / | PNP | 0.2 | -0.15 | -50 | 50 | -5 | 70 | 240 | -0.3 | 80 | SOT-23 | |
MMBTSA1182 | / | / | PNP | 0.2 | -0.5 | -35 | 30 | -5 | 25 | 240 | -0.25 | 200 | SOT-23 | |
MMBTSA1235 | / | / | PNP | 0.2 | -0.2 | -60 | 50 | -6 | 90 | 500 | -0.3 | 200 | SOT-23 | |
MMBTSA1256 | / | / | PNP | 0.2 | -0.03 | -30 | 20 | -5 | 60 | 270 | - | 150 | SOT-23 | |
MMBTSA1298 | / | / | PNP | 0.2 | -0.8 | -30 | 25 | -5 | 40 | 320 | -0.4 | 120 | SOT-23 | |
MMBTSA1365 | / | / | PNP | 0.2 | -0.7 | -25 | 20 | -4 | 150 | 800 | -0.5 | 180 | SOT-23 | |
MMBTSA1504 | / | / | PNP | 0.2 | -0.15 | -50 | 50 | -5 | 70 | 400 | -0.3 | 80 | SOT-23 | |
MMBTSA1505 | / | / | PNP | 0.2 | -0.5 | -35 | 30 | -5 | 25 | 400 | -0.25 | 200 | SOT-23 | |
MMBTSA1576 | / | / | PNP | 0.2 | -0.15 | -60 | 50 | -6 | 120 | 560 | -0.5 | 140 | SOT-23 | |
MMBTSA1979 | / | / | PNP | 0.2 | -0.5 | -40 | 32 | -5 | 70 | 240 | -0.25 | 200 | SOT-23 | |
MMBTSA1981 | / | / | PNP | 0.2 | -0.8 | -35 | 30 | -5 | 100 | 320 | -0.5 | 120 | SOT-23 | |
MMBTSA2018 | / | / | PNP | 0.2 | 0.5 | -15 | 12 | -6 | 270 | 680 | -0.25 | 260 | SOT-23 | |
MMBTSA733 | / | / | PNP | 0.2 | -0.15 | -60 | 50 | -5 | 40 | 700 | -0.3 | 50 | SOT-23 | |
MMBTSA812 | / | / | PNP | 0.2 | -0.1 | -60 | 50 | -5 | 90 | 600 | -0.3 | 180 | SOT-23 | |
MMBTSB1197 | / | / | PNP | 0.2 | -0.8 | -40 | 32 | -5 | 120 | 390 | -0.5 | 50 | SOT-23 | |
MMBTSB1198 | / | / | PNP | 0.2 | -0.5 | -80 | 80 | -5 | 120 | 390 | -0.5 | 180 | SOT-23 | |
MMBTSB1690 | / | / | PNP | 0.2 | 2 | -15 | 12 | -6 | 270 | 680 | -0.18 | 360 | SOT-23 | |
MMBTSB624 | / | / | PNP | 0.2 | -0.7 | -30 | 25 | -5 | 50 | 400 | -0.6 | 160 | SOT-23 | |
MMBTSB815 | / | / | PNP | 0.2 | -0.7 | -20 | 15 | -5 | 80 | 400 | -0.035 | 250 | SOT-23 | |
S8550(0.8A) | / | / | PNP | 0.3 | -0.5 | -40 | -25 | -5 | 120 | 400 | -0.6 | 150 | SOT-23 | |
S8550 | / | / | PNP | 0.3 | -0.5 | -40 | 25 | -5 | 50 | 350 | -0.6 | 150 | SOT-23 | |
S9012 | / | / | PNP | 0.3 | -0.5 | -40 | -25 | -5 | 120 | 200 | -0.6 | 150 | SOT-23 | |
S9015 | / | / | PNP | 0.2 | -0.1 | -50 | 45 | -5 | 200 | 450 | -0.3 | 150 | SOT-23 | |
SS8550N | / | / | PNP | 0.3 | -1.5 | -40 | -25 | -5 | 200 | 350 | -0.5 | 100 | SOT-23 | |
SS8550 | / | / | PNP | 0.3 | 1.5 | -40 | 25 | -5 | 40 | 350 | -0.5 | 100 | SOT-23 | |
2SA1586W | / | / | PNP | 0.1 | -0.15 | -50 | -50 | -5 | 70 | 400 | -0.3 | 80 | SOT-323 | |
2SA1611 | / | / | PNP | 0.15 | -0.1 | -60 | -50 | -5 | 90 | 600 | -0.3 | 180 | SOT-323 | |
2SA812W | / | / | PNP | 0.2 | -0.1 | -60 | -50 | -5 | 90 | 600 | -0.3 | 180 | SOT-323 | |
BC807W | / | / | PNP | 0.3 | -0.5 | -50 | -45 | -5 | 100 | 600 | -0.7 | 80 | SOT-323 | |
BC856AW | / | / | PNP | 0.15 | 0.1 | -80 | -65 | -5 | 110 | 220 | -0.65 | 100 | SOT-323 | |
BC856BW | / | / | PNP | 0.15 | 0.1 | -80 | -65 | -5 | 220 | 475 | -0.65 | 100 | SOT-323 | |
BC856CW | / | / | PNP | 0.15 | 0.1 | -80 | -65 | -5 | 420 | 800 | -0.65 | 100 | SOT-323 | |
BC857AW | / | / | PNP | 0.15 | 0.1 | -50 | -45 | -5 | 110 | 220 | -0.65 | 100 | SOT-323 | |
BC857BW | / | / | PNP | 0.15 | 0.1 | -50 | -45 | -5 | 200 | 450 | -0.65 | 100 | SOT-323 | |
BC857CW | / | / | PNP | 0.15 | 0.1 | -50 | -45 | -5 | 420 | 800 | -0.65 | 100 | SOT-323 | |
BC858AW | / | / | PNP | 0.15 | 0.1 | -30 | -30 | -5 | 110 | 220 | -0.65 | 100 | SOT-323 | |
BC858BW | / | / | PNP | 0.15 | 0.1 | -30 | -30 | -5 | 200 | 450 | -0.65 | 100 | SOT-323 | |
BC858CW | / | / | PNP | 0.15 | 0.1 | -30 | -30 | -5 | 420 | 800 | -0.65 | 100 | SOT-323 | |
BC859AW | / | / | PNP | 0.15 | 0.1 | -30 | -30 | -5 | 110 | 220 | -0.65 | 100 | SOT-323 | |
BC859BW | / | / | PNP | 0.15 | 0.1 | -30 | -30 | -5 | 200 | 450 | -0.65 | 100 | SOT-323 | |
BC859CW | / | / | PNP | 0.15 | 0.1 | -30 | -30 | -5 | 420 | 800 | -0.65 | 100 | SOT-323 | |
BC860AW | / | / | PNP | 0.15 | 0.1 | -50 | -45 | -5 | 110 | 220 | -0.65 | 100 | SOT-323 | |
BC860BW | / | / | PNP | 0.15 | 0.1 | -50 | -45 | -5 | 200 | 450 | -0.65 | 100 | SOT-323 | |
BC860CW | / | / | PNP | 0.15 | 0.1 | -50 | -45 | -5 | 420 | 800 | -0.65 | 100 | SOT-323 | |
MMBT2907AW | / | / | PNP | 0.2 | -0.6 | -60 | -60 | -5 | 100 | 300 | -0.4 | 200 | SOT-323 | |
MMBT3906W | / | / | PNP | 0.2 | -0.2 | -40 | -40 | -5 | 100 | 300 | -0.25 | 250 | SOT-323 | |
MMBT4403W | / | / | PNP | 0.2 | -0.6 | -40 | -40 | -5 | 100 | 300 | -0.4 | 200 | SOT-323 | |
MMBT5401W | / | / | PNP | 0.2 | -0.6 | -160 | -150 | -5 | 60 | 300 | -0.5 | 100 | SOT-323 | |
MMBT8550W(1.5A) | / | / | PNP | 0.2 | -1.5 | -40 | -25 | -5 | 100 | 400 | -0.5 | 100 | SOT-323 | |
MMBTA92W | / | / | PNP | 0.3 | -0.2 | -300 | -300 | -5 | 60 | - | -0.2 | 50 | SOT-323 | |
MMBTSA1576W | / | / | PNP | 0.2 | -0.15 | -60 | -50 | -6 | 120 | 560 | -0.5 | 30 | SOT-323 | |
MMBTSA1577W | / | / | PNP | 0.2 | -0.5 | -40 | -32 | -5 | 82 | 390 | -0.4 | 200 | SOT-323 | |
S8550W | / | / | PNP | 0.3 | -0.5 | -40 | -25 | -5 | 120 | 400 | -0.6 | 150 | SOT-323 | |
S8550W-0.8A | / | / | PNP | 0.25 | 0.8 | -40 | -25 | -5 | 120 | 400 | -0.6 | 150 | SOT-323 | |
S9012W | / | / | PNP | -0.2 | -0.5 | -40 | -25 | -5 | 120 | 400 | -0.6 | 150 | SOT-323 | |
S9015W | / | / | PNP | 0.2 | -0.1 | -50 | -45 | -5 | 200 | 1000 | -0.3 | 150 | SOT-323 | |
SS8550W | / | / | PNP | 0.2 | 1.5 | -40 | 25 | -5 | 120 | 400 | -0.5 | 100 | SOT-323 | |
2SB1694 | / | / | PNP | 0.2 | -1 | -30 | -30 | -6 | 270 | 680 | -0.38 | 320 | SOT-323 | |
2SA1774 | / | / | PNP | 0.15 | 0.15 | 60 | 50 | 6 | 120 | 560 | 0.5 | 140 | SOT-523 | |
BC856AT | / | / | PNP | 0.2 | -0.1 | -80 | -65 | -5 | 110 | 220 | =-0.3-0.65 | 100 | SOT-523 | |
BC856BT | / | / | PNP | 0.2 | -0.1 | -80 | -65 | -5 | 200 | 450 | =-0.3-0.65 | 100 | SOT-523 | |
BC856CT | / | / | PNP | 0.2 | -0.1 | -80 | -65 | -5 | 420 | 800 | =-0.3-0.65 | 100 | SOT-523 | |
BC856E | / | / | PNP | 0.15 | -0.1 | -80 | 65 | -5 | 125 | 250 | -0.3 | 100 | SOT-523 | |
BC857AT | / | / | PNP | 0.2 | -0.1 | -50 | -45 | -5 | 110 | 220 | =-0.3-0.65 | 100 | SOT-523 | |
BC857BT | / | / | PNP | 0.2 | -0.1 | -50 | -45 | -5 | 200 | 450 | =-0.3-0.65 | 100 | SOT-523 | |
BC857CT | / | / | PNP | 0.2 | -0.1 | -50 | -45 | -5 | 420 | 800 | =-0.3-0.65 | 100 | SOT-523 | |
BC857E | / | / | PNP | 0.15 | -0.1 | -50 | 45 | -5 | 125 | 250 | -0.3 | 100 | SOT-523 | |
BC858AT | / | / | PNP | 0.2 | -0.1 | -30 | -30 | -5 | 110 | 220 | =-0.3-0.65 | 100 | SOT-523 | |
BC858BT | / | / | PNP | 0.2 | -0.1 | -30 | -30 | -5 | 200 | 450 | =-0.3-0.65 | 100 | SOT-523 | |
BC858CT | / | / | PNP | 0.2 | -0.1 | -30 | -30 | -5 | 420 | 800 | =-0.3-0.65 | 100 | SOT-523 | |
BC858E | / | / | PNP | 0.15 | -0.1 | -30 | 30 | -5 | 125 | 250 | -0.3 | 100 | SOT-523 | |
BC859AT | / | / | PNP | 0.2 | -0.1 | -30 | -30 | -5 | 110 | 220 | =-0.3-0.65 | 100 | SOT-523 | |
BC859BT | / | / | PNP | 0.2 | -0.1 | -30 | -30 | -5 | 200 | 450 | =-0.3-0.65 | 100 | SOT-523 | |
BC859CT | / | / | PNP | 0.2 | -0.1 | -30 | -30 | -5 | 420 | 800 | =-0.3-0.65 | 100 | SOT-523 | |
BC859E | / | / | PNP | 0.15 | -0.1 | -30 | 30 | -5 | 125 | 250 | -0.3 | 100 | SOT-523 | |
BC860AT | / | / | PNP | 0.2 | -0.1 | -50 | -45 | -5 | 110 | 220 | =-0.3-0.65 | 100 | SOT-523 | |
BC860BT | / | / | PNP | 0.2 | -0.1 | -50 | -45 | -5 | 200 | 450 | =-0.3-0.65 | 100 | SOT-523 | |
BC860CT | / | / | PNP | 0.2 | -0.1 | -50 | -45 | -5 | 420 | 800 | =-0.3-0.65 | 100 | SOT-523 | |
BC860E | / | / | PNP | 0.15 | -0.1 | -50 | 45 | -5 | 125 | 250 | -0.3 | 100 | SOT-523 | |
MMBT3906E | / | / | PNP | 0.35 | 0.2 | -40 | -40 | -6 | 100 | 300 | -0.25 | 250 | SOT-523 | |
MMBT3906T | / | / | PNP | 0.15 | -0.2 | -40 | -40 | -5 | 100 | 300 | -0.25 | 250 | SOT-523 | |
MMBT5401T | / | / | PNP | 0.2 | 0.6 | 160 | 150 | 5 | 50 | 300 | 0.15 | 100 | SOT-523 | |
MMBTSA1015E | / | / | PNP | 0.15 | -0.15 | -50 | 50 | -5 | 70 | 140 | -0.3 | 80 | SOT-523 | |
MMBTSA1774E | / | / | PNP | 0.15 | -0.15 | -60 | 50 | -6 | 120 | 560 | -0.5 | 140 | SOT-523 | |
MMBTSA1980E | / | / | PNP | 0.15 | -0.15 | -50 | 50 | -5 | 70 | 140 | -0.3 | 80 | SOT-523 | |
MMDTA114EE | / | / | PNP | 0.15 | -0.1 | - | -50 | - | 30 | - | -0.3 | 250 | SOT-523 | |
MMDTA114YE | / | / | PNP | - | -0.1 | 50 | 50 | -5 | 68 | - | -0.3 | 100 | SOT-523 | |
S8550T | / | / | PNP | 0.3 | 0.5 | 40 | 25 | 5 | 200 | 350 | 0.5 | 150 | SOT-523 | |
S8550T-0.8A | / | / | PNP | 0.2 | 0.8 | -40 | -25 | -5 | 200 | 350 | -0.6 | 150 | SOT-523 | |
S9012T | / | / | PNP | 0.3 | 0.5 | 40 | -65 | -5 | 120 | 400 | 0.5 | 150 | SOT-523 | |
S9015T | / | / | PNP | 0.2 | 0.1 | 50 | 45 | 5 | 200 | 450 | 0.3 | 150 | SOT-523 | |
MMBT2907AT | / | / | PNP | 0.2 | -0.6 | -60 | -60 | -5 | 100 | 300 | -1.6 | 200 | SOT-523 | |
MMBT3906M | / | / | PNP | 0.2 | 0.2 | 60 | 40 | 5 | 100 | 300 | 0.3 | 300 | SOT-723 | |
2N2907A | / | / | PNP | 0.625 | -0.6 | -60 | -60 | -5 | 100 | 300 | -0.4 | 200 | SOT-89 | |
2N2907 | / | / | PNP | 0.625 | -0.6 | -60 | -40 | -5 | 100 | 300 | -0.4 | 200 | SOT-89 | |
2N3906 | / | / | PNP | 0.5 | -0.2 | -40 | -40 | -6 | 100 | 300 | -0.4 | 250 | SOT-89 | |
2N5401 | / | / | PNP | 0.5 | -0.5 | -160 | -150 | -5 | 60 | 300 | -0.5 | 100 | SOT-89 | |
2SA1013 | / | / | PNP | 0.5 | 1 | -160 | 160 | -6 | 60 | 320 | -1.5 | 15 | SOT-89 | |
2SA1020 | / | / | PNP | 0.5 | -2 | -50 | -50 | -5 | 70 | 240 | -0.5 | 100 | SOT-89 | |
2SA1201 | / | / | PNP | 0.5 | -0.8 | -120 | 120 | -5 | 80 | 240 | -1 | 120 | SOT-89 | |
2SA1203 | / | / | PNP | 0.5 | -1.5 | -30 | -30 | -5 | 100 | 320 | -2 | 120 | SOT-89 | |
2SA1213 | / | / | PNP | 0.5 | -2 | -50 | -50 | -5 | 70 | 240 | -0.5 | 100 | SOT-89 | |
2SA1661 | / | / | PNP | 0.5 | 0.8 | 120 | 120 | 5 | 80 | 120 | 1 | 120 | SOT-89 | |
2SA1663 | / | / | PNP | 1 | 1.5 | 30 | 30 | 5 | 100 | 320 | 2 | 120 | SOT-89 | |
2SA1664 | / | / | PNP | 0.5 | -0.8 | -35 | 30 | -5 | 100 | 320 | -0.7 | 120 | SOT-89 | |
2SA1666 | / | / | PNP | 0.5 | 2 | 50 | 50 | 5 | 70 | 240 | 0.5 | 120 | SOT-89 | |
2SA1797 | / | / | PNP | 0.5 | -2 | -50 | -50 | -6 | 82 | 270 | -0.35 | 200 | SOT-89 | |
2SA1900 | / | / | PNP | 0.5 | 1 | 60 | 50 | 5 | 120 | 270 | 0.4 | 150 | SOT-89 | |
2SA2071 | / | / | PNP | 0.5 | 3 | 60 | 60 | 6 | 100 | 270 | 0.2 | 180 | SOT-89 | |
2SAR542P | / | / | PNP | 0.5 | -5 | -30 | -30 | -6 | 200 | 500 | -0.4 | 240 | SOT-89 | |
2SB1123 | / | / | PNP | 0.5 | -2 | -60 | -50 | -6 | 100 | 560 | <-0.7 | 150 | SOT-89 | |
2SB1188 | / | / | PNP | 0.5 | 2 | 40 | 32 | 5 | 82 | 390 | 0.8 | 100 | SOT-89 | |
2SB1189 | / | / | PNP | 0.5 | 0.7 | -80 | -80 | -5 | 82 | 390 | -0.4 | 100 | SOT-89 | |
2SB1260 | / | / | PNP | 0.5 | -1 | -80 | -80 | -5 | 82 | 390 | -0.4 | 100 | SOT-89 | |
2SB1386 | / | / | PNP | 0.5 | 5 | 30 | 20 | 6 | 82 | 390 | 1 | 120 | SOT-89 | |
2SB1424 | / | / | PNP | 0.5 | 3 | 20 | 20 | 6 | 120 | 390 | 0.5 | 240 | SOT-89 | |
2SB1440 | / | / | PNP | 0.5 | -2 | -50 | -50 | -5 | 120 | 340 | -0.3 | 80 | SOT-89 | |
2SB1561 | / | / | PNP | 2 | 2 | -60 | 60 | -6 | 120 | 270 | -0.35 | 200 | SOT-89 | |
2SB649 | / | / | PNP | 1 | -1.5 | -180 | -120 | -5 | 60 | 320 | -1 | 140 | SOT-89 | |
2SB805 | / | / | PNP | 2 | -0.7 | -100 | -100 | -5 | 90 | 400 | -0.6 | 75 | SOT-89 | |
2SB806 | / | / | PNP | 2 | -0.7 | -120 | -120 | -5 | 90 | 400 | -0.6 | 75 | SOT-89 | |
PXT8550 | / | / | PNP | 0.5 | -1.5 | -40 | -25 | -5 | 120 | 400 | -0.5 | 100 | SOT-89 | |
BC869U | / | / | PNP | 0.5 | -1 | -32 | -20 | -5 | 100 | 375 | <-0.5 | >40 | SOT-89 | |
BCX51 | / | / | PNP | 0.5 | 1 | -45 | 45 | -5 | 63 | 250 | -0.5 | 50 | SOT-89 | |
BCX52 | / | / | PNP | 0.5 | 1 | -60 | 60 | -5 | 63 | 250 | -0.5 | 50 | SOT-89 | |
BCX53 | / | / | PNP | 0.5 | 1 | -100 | 80 | -5 | 63 | 250 | -0.5 | 50 | SOT-89 | |
FCX591 | / | / | PNP | 0.5 | -1 | -80 | -60 | -5 | 100 | 300 | -0.3 | 150 | SOT-89 | |
MMBT4403 | / | / | PNP | 0.5 | -0.6 | -40 | -40 | -5 | 100 | 300 | -0.4 | 200 | SOT-89 | |
MPSA92 | / | / | PNP | 0.5 | -500 | - | - | - | - | >40 | -0.5 | 50 | SOT-89 | |
MPSA94 | / | / | PNP | 0.625 | 0.3 | 400 | 400 | 6 | 80 | 300 | 0.2 | - | SOT-89 | |
PBSS5320 | / | / | PNP | 0.6 | -2 | -20 | -20 | -5 | 220 | 450 | -0.1 | 100 | SOT-89 | |
S8550 | / | / | PNP | 0.3 | 0.8 | 40 | 25 | 6 | 120 | 300 | 0.5 | 120 | SOT-89 | |
S9015 | / | / | PNP | 0.5 | 0.1 | -50 | -45 | -5 | 200 | 450 | -0.3 | 150 | SOT-89 | |
SS8550 | / | / | PNP | 0.3 | 1.5 | 40 | 25 | 5 | 40 | 450 | 0.5 | 100 | SOT-89 | |
2SA1417 | / | / | PNP | 0.5 | -2 | -120 | -100 | -6 | 100 | 400 | -0.6 | -120 | SOT-89 | |
2SB1027 | / | / | PNP | 1 | -1.5 | -180 | -120 | -5 | 60 | 320 | -1 | - | SOT-89 | |
2SB766 | / | / | PNP | 0.5 | -1 | -30 | -25 | -5 | 85 | 340 | -0.4 | 200 | SOT-89 | |
BC818B | / | / | PNP | 0.35 | -3 | -30 | -30 | -5 | 100 | - | -0.8 | - | SOT23-6L | |
BC818A | / | / | PNP | 0.35 | 1.5 | -30 | -25 | -8 | 100 | 360 | -0.5 | - | SOT23-6L | |
BC818C | / | / | PNP | 1 | -2 | -30 | -30 | -5 | 100 | 300 | -0.18 | - | SOT23-6L | |
MMDT2907AF | / | / | PNP+PNP | 0.25 | -0.6 | -60 | -60 | -5 | 100 | 300 | -0.4 | 200 | SOT23-6L | |
MMBT5401DW | / | / | PNP+PNP | 0.3 | -0.6 | -160 | -150 | -5 | 60 | 300 | -0.2 | 100 | SOT23-6L | |
BC856S | / | / | PNP+PNP | 0.2 | -0.1 | -80 | -65 | -5 | 125 | 800 | =-0.3-0.65 | 100 | SOT-363 | |
BC807DW | / | / | PNP+PNP | 0.3 | -0.5 | -50 | -45 | -5 | 160 | 400 | -0.7 | 200 | SOT-363 | |
BC846PN | / | / | NPN+PNP | 0.2 | 0.1 | 80 | 65 | 6 | 200 | 450 | 0.25 | 100 | SOT-363 | |
BC856DW | / | / | PNP+PNP | 0.2 | -0.1 | -80 | -65 | -5 | 110 | 600 | -0.3 | 100 | SOT-363 | |
BC857DW | / | / | PNP+PNP | 0.3 | -2 | -50 | -45 | -5 | 125 | 630 | -0.65 | 100 | SOT-363 | |
MMBT5541DW | / | / | PNP+NPN | 0.2 | 0.2 | 180 | 160 | 6 | 100 | 300 | 0.2 | 100 | SOT-363 | |
MMBTSC5201DW | / | / | PNP | 0.25 | 0.1 | 50 | 45 | 5 | 220 | 475 | 0.2 | 100 | SOT-363 | |
MMDT2907ADW | / | / | PNP+PNP | 0.2 | -0.6 | -60 | -60 | -5 | 100 | 300 | -0.4 | 200 | SOT-363 | |
MMDT3906DW | / | / | PNP+PNP | 0.2 | -0.2 | -40 | -40 | -5 | 100 | 300 | -0.25 | 250 | SOT-363 | |
MMDT4413DW | / | / | NPN+PNP | 0.2 | 0.6,-0.6 | 60,-40 | 40,-40 | 6,-5 | 100 | 300 | 0.4 | 250 | SOT-363 | |
MMDT5401DW | / | / | PNP+PNP | 0.3 | -0.6 | -160 | -150 | -5 | 60 | 300 | -0.2 | 100 | SOT-363 | |
MMDT5451DW | / | / | PNP+NPN | 0.2 | 0.2,-0.2 | 180,-160 | 160,-150 | 6,-5 | 100 | 300 | 0.2 | 100 | SOT-363 | |
MMDT9012DW | / | / | PNP+PNP | 0.3 | -0.5 | -40 | -25 | -5 | 120 | 400 | -0.6 | 150 | SOT-363 | |
MMDT9015DW | / | / | PNP+PNP | 0.2 | -0.1 | -50 | -45 | -5 | 300 | 400 | -0.3 | 150 | SOT-363 | |
MMDT4403DW | / | / | PNP+PNP | 0.2 | -0.6 | -40 | -40 | -5 | 100 | 300 | -0.75 | 250 | SOT-363 | |
BC856V | / | / | PNP | 0.2 | -0.1 | -80 | -65 | -5 | 200 | 450 | =-0.3-0.65 | 100 | SOT-563 | |
BC857BV | / | / | PNP+PNP | 0.15 | -0.1 | -50 | -45 | -5 | 220 | 475 | -0.4 | 100 | SOT-563 | |
MMDT3906V | / | / | PNP | 0.35 | -0.2 | -40 | 40 | -6 | 30 | 300 | -0.3 | 300 | SOT-563 | |
MMDT5401V | / | / | PNP+PNP | 0.3 | -0.6 | -160 | -150 | -5 | 60 | 300 | -0.2 | 10 | SOT-563 | |
S8550V | / | / | PNP | 0.3 | -0.5 | -40 | 25 | -5 | 50 | 350 | -0.6 | 150 | SOT-563 |
