| Type | Datasheet | Circuit | Marking | IT(RMS) | ITSM@50Hz | VDRM | VRRM | IGT(1-3) | TJ | Package |
| A | A | V | V | mA | ℃ | |||||
| 重置全部 | / | / | / |
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
OK
|
Reset
|
| / | / | / | ||||||||
| BT131G-600 |
|
|
1 | 16 | 600 | 600 | 5 | 125 | TO-92 | |
| BT131G-800 |
|
|
1 | 16 | 800 | 800 | 5 | 125 | TO-92 | |
| BT132G-600 |
|
|
2 | 16 | 600 | 600 | 5 | 125 | TO-92 | |
| BT132G-800 |
|
|
2 | 16 | 800 | 800 | 5 | 125 | TO-92 | |
| MAC97A6G |
|
|
0.8 | 8 | 600 | 600 | 5 | 125 | TO-92 | |
| MAC97A8G |
|
|
0.8 | 8 | 800 | 800 | 5 | 125 | TO-92 | |
| MAC97A6 | / | / | 0.8 | 8 | 600 | 600 | 5 | 125 | SOT23-3L | |
| BT131S-600 | / | / | 1 | 16 | 600 | 600 | 5 | 125 | SOT-223 | |
| BT131S-800 | / | / | 1 | 16 | 800 | 800 | 5 | 125 | SOT-223 | |
| BT131W-600 |
|
|
1 | 16 | 600 | 600 | 5 | 125 | SOT-223-2L | |
| BT131W-800 |
|
|
1 | 16 | 800 | 800 | 5 | 125 | SOT-223-2L | |
| Z0607NT |
|
|
1 | 12 | 800 | 800 | 7 | 125 | SOT-223-2L | |
| BT134W-600E |
|
|
2 | 20 | 600 | 600 | 0.02 | 125 | SOT-223 | |
| BT134W-800E |
|
|
2 | 20 | 800 | 800 | 0.02 | 125 | SOT-223 | |
| BT134-600E | / | / | 4 | 25 | 600 | 600 | 10 | 125 | TO-126 | |
| BT134-800E | / | / | 4 | 25 | 800 | 800 | 10 | 125 | TO-126 | |
| BT136-600D |
|
|
4 | 25 | 600 | 600 | 5 | 125 | TO-220C | |
| BT136-800D |
|
|
4 | 25 | 800 | 800 | 5 | 125 | TO-220C | |
| BT136-600E |
|
|
4 | 25 | 600 | 600 | 10 | 125 | TO-220C | |
| BT136-800E |
|
|
4 | 25 | 800 | 800 | 10 | 125 | TO-220C | |
| BT137-600D |
|
|
8 | 65 | 600 | 600 | 5 | 125 | TO-220C | |
| BT137-800D |
|
|
8 | 65 | 800 | 800 | 5 | 125 | TO-220C | |
| BT137-600E |
|
|
8 | 65 | 600 | 600 | 10 | 125 | TO-220C | |
| BT137-800E |
|
|
8 | 65 | 800 | 800 | 10 | 125 | TO-220C | |
| BT137-600F |
|
|
8 | 65 | 600 | 600 | 25 | 125 | TO-220C | |
| BT137-800F |
|
|
8 | 65 | 800 | 800 | 25 | 125 | TO-220C | |
| BT138-600D | / | / | 12 | 95 | 600 | 600 | 5 | 125 | TO-220C | |
| BT138-800D | / | / | 12 | 95 | 800 | 800 | 5 | 125 | TO-220C | |
| BT138-600E | / | / | 12 | 95 | 600 | 600 | 10 | 125 | TO-220C | |
| BT138-800E | / | / | 12 | 95 | 800 | 800 | 10 | 125 | TO-220C | |
| BT138-600F | / | / | 12 | 95 | 600 | 600 | 25 | 125 | TO-220C | |
| BT138-800F | / | / | 12 | 95 | 800 | 800 | 25 | 125 | TO-220C | |
| BT139-600E | / | / | 16 | 140 | 600 | 600 | 10 | 125 | TO-220C | |
| BT139-800E | / | / | 16 | 140 | 800 | 800 | 10 | 125 | TO-220C | |
| BTA04F-600E | / | / | 4 | 40 | 600 | 600 | 35 | 125 | TO-220F | |
| BTA04F-800E | / | / | 4 | 40 | 800 | 800 | 35 | 125 | TO-220F | |
| BT136F-600D | / | / | 4 | 25 | 600 | 600 | 5 | 125 | TO-220F | |
| BT136F-800D | / | / | 4 | 25 | 800 | 800 | 5 | 125 | TO-220F | |
| BT136F-600E | / | / | 4 | 25 | 600 | 600 | 10 | 125 | TO-220F | |
| BT136F-800E | / | / | 4 | 25 | 800 | 800 | 10 | 125 | TO-220F | |
| BT139F-600D | / | / | 16 | 150 | 600 | 600 | 15 | 125 | TO-220F | |
| BT139F-800D | / | / | 16 | 150 | 800 | 800 | 15 | 125 | TO-220F | |
| BT139F-600E | / | / | 16 | 150 | 600 | 600 | 25 | 125 | TO-220F | |
| BT139F-800E | / | / | 16 | 150 | 800 | 800 | 25 | 125 | TO-220F | |
| BTA06A-600E |
|
|
6 | 60 | 600 | 600 | 10 | 125 | TO-220A | |
| BTA06A-600D |
|
|
6 | 60 | 600 | 600 | 25 | 125 | TO-220A | |
| BTA06A-600C |
|
|
6 | 60 | 600 | 600 | 50 | 125 | TO-220A | |
| BTA06A-800E |
|
|
6 | 60 | 800 | 800 | 10 | 125 | TO-220A | |
| BTA06A-800D |
|
|
6 | 60 | 800 | 800 | 25 | 125 | TO-220A | |
| BTA06A-800C |
|
|
6 | 60 | 800 | 800 | 50 | 125 | TO-220A | |
| BTA12-600E |
|
|
12 | 120 | 600 | 600 | 10 | 125 | TO-220A | |
| BTA12-600C |
|
|
12 | 120 | 600 | 600 | 25 | 125 | TO-220A | |
| BTA12-600B |
|
|
12 | 120 | 600 | 600 | 50 | 125 | TO-220A | |
| BTA12-800E |
|
|
12 | 120 | 800 | 800 | 10 | 125 | TO-220A | |
| BTA12-800C |
|
|
12 | 120 | 800 | 800 | 25 | 125 | TO-220A | |
| BTA12-800B |
|
|
12 | 120 | 800 | 800 | 50 | 125 | TO-220A | |
| BTA16-600C |
|
|
16 | 160 | 600 | 600 | 25 | 125 | TO-220A | |
| BTA16-600B |
|
|
16 | 160 | 600 | 600 | 50 | 125 | TO-220A | |
| BTA16-800C |
|
|
16 | 160 | 800 | 800 | 25 | 125 | TO-220A | |
| BTA16-800B |
|
|
16 | 160 | 800 | 800 | 50 | 125 | TO-220A | |
| BTA24-600C |
|
|
24 | 240 | 600 | 600 | 50 | 125 | TO-220A | |
| BTA24-600B |
|
|
24 | 240 | 600 | 600 | 120 | 125 | TO-220A | |
| BTA24-800C |
|
|
24 | 240 | 800 | 800 | 50 | 125 | TO-220A | |
| BTA24-800B |
|
|
24 | 240 | 800 | 800 | 120 | 125 | TO-220A | |
| BTB16-600B |
|
|
16 | 125 | 600 | 600 | 50 | 125 | TO-220B | |
| BTB16-800B |
|
|
16 | 125 | 800 | 800 | 50 | 125 | TO-220B | |
| BTB16-600C |
|
|
16 | 125 | 600 | 600 | 25 | 125 | TO-220B | |
| BTB16-800C |
|
|
16 | 125 | 800 | 800 | 25 | 125 | TO-220B | |
| BTB24-600B |
|
|
24 | 240 | 600 | 600 | 120 | 125 | TO-220B | |
| BTB24-800B |
|
|
24 | 240 | 800 | 800 | 120 | 125 | TO-220B | |
| BTB24-600C |
|
|
24 | 240 | 600 | 600 | 50 | 125 | TO-220B | |
| BTB24-800C |
|
|
24 | 240 | 800 | 800 | 50 | 125 | TO-220B | |
| BT136D-600E | / | / | 4 | 25 | 600 | 600 | 10 | 125 | TO-252 | |
| BT136D-800E | / | / | 4 | 25 | 800 | 800 | 10 | 125 | TO-252 | |
| BT137D-600E | / | / | 8 | 65 | 600 | 600 | 10 | 125 | TO-252 | |
| BT137D-800E | / | / | 8 | 65 | 800 | 800 | 10 | 125 | TO-252 | |
| BT138D-600E | / | / | 12 | 95 | 600 | 600 | 10 | 125 | TO-252 | |
| BT138D-800E | / | / | 12 | 95 | 800 | 800 | 10 | 125 | TO-252 | |
| BT137Q-600E | / | / | 8 | 65 | 600 | 600 | 10 | 125 | TO-263 | |
| BT137Q-800E | / | / | 8 | 65 | 800 | 800 | 10 | 125 | TO-263 | |
| BT139Q-600D | / | / | 16 | 140 | 600 | 600 | 5 | 125 | TO-263 | |
| BT139Q-800D | / | / | 16 | 140 | 800 | 800 | 5 | 125 | TO-263 | |
| BT139Q-600E | / | / | 16 | 140 | 600 | 600 | 10 | 125 | TO-263 | |
| BT139Q-800E | / | / | 16 | 140 | 800 | 800 | 10 | 125 | TO-263 | |
| BT139Q-600F | / | / | 16 | 140 | 600 | 600 | 25 | 125 | TO-263 | |
| BT139Q-800F | / | / | 16 | 140 | 800 | 800 | 25 | 125 | TO-263 | |
| BTB16Q-600C | / | / | 16 | 160 | 600 | 600 | 50 | 125 | TO-263 | |
| BTB16Q-800C | / | / | 16 | 160 | 800 | 800 | 50 | 125 | TO-263 |
